MPO APC to 12 LC UPC Patch Cord Single Mode OS2 9/125 G652D 2.0mm PVC 1m 3m 5m 10m

Descriptions:

- The single-mode and multimode MPO products are multi fiber connectors used in high-density backplane and Printed Circuit Board(PCB) applications in data and telecommunications system.

- The single mode MPO patch cord is available in G652D, G655, G657A1, G657A2 and G657B3 fiber.

- The MPO patch cord can do with one side is MPO connector and other side is MPO connector or other type connector such as SC, LC, FC, ST, E2000, D4, DIN, MU, ... as customer request.

- The MPO can be mass terminated in combination of 4, 8, 12 or 24 fibers.

- The MPO connector offers up to 12 times the density of standard connectors, providing significant space and cost savings.
- MPO patch cord utilize precision molded MT ferrules, with metal guide pins and precise housing dimensions to ensure fiber alignment when mating.
- MTP/MPO multi-fiber trunk cables are usually in mini-round cables and ribbon cables, with fanout kits broken down into 2~24 fiber 0.9mm or 2.0mm tails with connector LC, SC, ST, FC, etc.

- Cable total length, fanout length, connector type are customized.

Features:

- Fiber in single connector: 4, 8, 12, 24

- Insert/Pull latching connector

- High reflection loss with APC

- Single mode and multi mode (flat) APC (catercorner 8 degree angled) are available

- High fiber density (maximum 24 fibers for Multimode)

- Comply with Telcordia GR-1435-CORE specification and Rosh standard

Applications:

- Telecommunication Networks

- Parallel optical interconnect between PC Cards and patch panels

- Interconnection for O/E modules

- Industrial & Military

- Optical Switch interframe connections

- FTTX (FTTH, FTTB, FTTO, FTTA, ...)

- Asynchronous Transmission Mode(ATM)

- Metro

- Gigabit Ethernet

- Active Deviced/Transceiver Interface

- CATV, Video and Multimedia

- Premise Installations

- Data center

Specifications:

Product Construction:

A: MPO connectot

L: Total length

L1: Fanout length

B: Connector ( FC, LC, ST, SC, ...)

Ordering Informations:

MPO/PC–MPO/PC-SM-12CORE–2M-LSZH

① ② ③ ④ ⑤ ⑥

Notices:

①Connector type: FC, SC, LC, ST, MTRJ, MU, E2000, MPO, DIN, D4, SMA

②Ferrule End-face: PC, UPC, APC

③Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)

④Fiber Quantity: 4 core, 8 core, 12 core, 24 core

⑤Cable Length: 1, 2, 3 meter or customized

⑥ Cable type: PVC, LSZH, OM3, OFNR, OFNP, Plenum

OEM/ODM Service:

If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.

Packing:

According to Stardard Export Packing.

Carton box, wooden box, wooden pallet.

Shipping:

- International express such as UPS, TNT, DHL, etc

- Internatioal air: CA, AA, EA, etc

- By sea
