Specifications
Brand Name :
SINOHONE
Model Number :
HY-634I
Certification :
RoHS ISO9001 CPR FCC CE
Place of Origin :
Sichuan, China
MOQ :
1 piece
Price :
USD 38~48/piece
Payment Terms :
L/C, T/T, MoneyGram, Western Union
Supply Ability :
50000 pieces per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Gigabit 7 Port Fiber Optic Switch
Exchange Capacity :
53Mpps
Mpps :
10.4Mpps
SFP Port :
3 gigabit port
RJ45 Port :
4 gigabit port
POE Power Supply :
Nonsupport
PTN Ring Networking :
Support
Management :
Support
Application :
Industrial Automation Fields
Description

3 Gigabit SFP And 4 Gigabit Electric 7 port Multimode Fiber Optic Switch

Quick Details:

HY-634I is one of our gigabit industrial fiber optical switch and widely used in power automation, factory automation, coal mine automation, rail transit, wind power and other automation fields.

It provides 3 1000M SFP or other specified optic port forms and 4 1000M electric ports. Its ability of supporting PTN ring network helps to achieve efficient network management and makes the network maintanance means effectively unified.

Other Applications
  1. Metallurgical
  2. Petrolem and petrochemical
  3. Road traffic control automation
  4. Building automation control system
  5. Environmental protection monitoring
  6. Other industries automation

Model No. HY-644I
Number of interference

Gigabit SFP ports (or specify other optical port forms): 4

Gigabit ports: 4
POE power supply Nonsupport
POE power supply standard Nonsupport
Exchange capacity 53G
Mpps 11.9Mpps
PTN ring network PTN industrial ring network technology, using ERPS protocol, STP protocol
VLAN

Support 4K VLAN, VLAN conversion function, VLAN based on port, MAC, protocol, IP address and QinQ

MAC

8K MAC address table, support MAC address table dynamic automatic learning and static configuration

QOS

Support 8 level QOS queue, support SP, WRR queue scheduling policy

ACL

The number of ACL entries can be supported to 256

Management
  1. Support local Console serial port and TELNET command line management; SSH; SNMP, WEB management
  2. Makes the network maintanance means effectively unified
  3. Helps to achieve efficient network management
Other Features

  • Port convergence /LACP supported, support 1:1 port protection

  • Support interport protection based on the LACP protocol, linear protection based on the G.8031 protocol and ring network protection based on the G.8032 protocol

  • Support port redirection and port mirror function, support port-based failover capabilities

  • Support MSTP/RSTP protocol

  • Support fiber breakage alarm;Support power failure warning of Dying Gasp remote device

  • Support equipment online upgrade

  • Support storm suppression and port speed limit, speed limit granules up to 64K

  • Support SLA, Link performance tests such as link delay, jitter, packet loss and throughput can be implemented

  • Support port-based, 802.1p, DSCP, TOS, MAC address, VLAN ID, Ethernet Type

Operating temperature

Industrial grade: (-40 ° C~ 80 ° C)

Storage temperature

-40°C～85°C

Multimode Fiber Optic Network Switch Electric 7 Port For Industrial Automation FieldsMultimode Fiber Optic Network Switch Electric 7 Port For Industrial Automation Fields
