Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Specifications
Brand Name :
SINOHONE
Model Number :
HY-624I
Certification :
CPR FCC CE RoHS ISO9001
Place of Origin :
Sichuan, China
MOQ :
1 piece
Price :
USD 38~48/piece
Payment Terms :
L/C, T/T, MoneyGram, Western Union
Supply Ability :
50000 pieces per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Secure PTN Fiber Optic Switch
QOS :
Level 8
Case :
Metal
PTN :
PTN ring network
Exchange Capacity :
53G
Mpps :
8.9Mpps
Management :
Managed
Power Supply :
DC / AC power
ACL :
256
Install :
Guide rail
Usage :
Industrial grade
Model No. :
HY-624I
Description

Stable PTN Ring Network Secure System 2 Port Gigabit SFP Fiber Optic Network Switch

Description:

HY-628I is one of our new generation intelligent industrail management gigabit optic switch. It has 2 gigabit SFP port (or other specified port form) and 4 gigabit RJ45 ports.

It can be also used as PTN remote equipment, for its ablility to connect with PTN ring network and simplify the operation interface. It also makes the network maintannce methods effective and unfied and helps to achieve efficient network management.

Advantages:

  1. It can be used as PTN remote equipment
  2. Low power consumption without fan
  3. This product can provide high-speed Ethernet service access and support Ethernet standard protocol.
  4. It simplifies the complex protocol overhead of PTN and provides the OAM capability of service layer, which makes the design and implementation of access network more concise.
  5. Its a device that enables optical signals to be selectively switched-on and -off or switched from one channel to another.
  6. It's widely used in automation fields such as power, factory and rail transit.

Application:

  1. Power Automation
  2. Factory Automation
  3. Rail Transit Automation
  4. Spot Scenic Security
  5. Expressway Monitoring

Product Name Automatic Monitoring Network Switch
Model No. HY-628I
Sample Picture Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
Exchange capacity 53G
Mpps 17.85Mpps
Number of interference

Gigabit SFP ports (or specify other optical port forms): 2

Gigabit ports: 8
Management Support
PTN Support PTN ring network

Operating temperature

Industrial grade: (-40 ° C~ 80 ° C)

Storage temperature

-40°C～85°C
Management
  • Support local Console serial port and TELNET command line management;
  • Support SSH;
  • Support SNMP, WEB management;
  • Support the unified management through the EMS management system independently developed by our company;
  • Support remote device software upgrade and backup through FTP and TFTP;
  • Support RMON performance statistics for ports
Features
  1. Support 4K VLAN, VLAN conversion function, VLAN based on port, MAC, protocol, IP address and QinQ
  2. Support PTN industrial ring network technology, using ERPS protocol, STP protocol
  3. 8K MAC address table, support MAC address table dynamic automatic learning and static configuration
  4. The number of ACL entries can be supported to 256
  5. 53G exchange capacity
  6. 8 level QOS queue, support SP, WRR queue scheduling policy
  7. PTN ring network
Power and power supply
  • No fan, low power consumption, the total power consumption of the equipment is less than 10W
  • Industrial grade supports dc or ac power (dc parameters: default -48v: -36v ~ -72v, ac parameters: default 220V:100V ~ 260V)

Other Application

  • Building automatic control system
  • Oilfielf control automation
  • Hydropower station control automation
  • Computer room monitoring system
  • Water conservancy monitoring
  • Environmental protection monitoring
  • Metallurgical, petroleum and petrochemical, road traffic control automation

Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch

Packing and Delivery

Secure PTN 2 Port Ethernet Switch , Stable Fiber Optic Cable Connect Switch
