Multimode Air Blown Fiber Optic Cable Cable Friendly Installation Diameter 2.5 Mm ~ 6 Mm
Multimode Air Blown Fiber Optic Cable Cable Friendly Installation Diameter 2.5 Mm ~ 6 Mm
Specifications
Brand Name :
SINOHONE
Model Number :
ABF
Certification :
CPR FCC CE RoHS ISO9001
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Air-blown fiber optical cable
Material :
HDPE, PA or other materials
Color :
Black or other colors
Appplications :
Indoors, Ships, Outdoors including FTTH
Fiber Count :
1 ~72 Fibers
Cable Diameter :
2.5 mm ~ 6 mm
Description

2 4 6 8 12 Fibers Air Blown Fiber Optic Cable 12 Core Multimode Fiber Optic Cable

Description

Sinohone has produced various air blown fiber cable types which are of good performance and compose a complete series of air blown products.

Air blowing fiber is the important part of the series, and it is the most popular product of the indoor optical fiber cables for generic cabling in Europe, Japan, South Korea and so on.

Characteristic

  • The tubes come in many designs with single or some number of tubes inside a single jacket.
  • Cables of tubes are installed like regular cables, meeting usual building codes.
  • Couplings provide connections between tubes for longer runs or branching.
  • Boxes of various designs allow routing tubes or terminating fibers.

Advantages:

  • Air-blown fiber (ABF) is an ideal solution for time-critical and/or challenging data cable installations.
  • Air-blown fiber also reduces future expansion costs and installation time by laying a foundation where additional fiber cables are added to an existing containing cable more efficiently.
  • The fiber are coated with a soft acrylate resin.
  • The outer sheath is a thermoplastic that is of low friction.
  • The surface of the sheath is designed with special grooves, compared to the surface of the traditional optical fiber cable.
  • It provides not only the high level of mechanical protection, but also the perfect blowing performance.

Specifications:

Fiber SM: G652D. G655. G657 or other single-mode optical fibers.
MM: Ala. Alb or other multi-mode fibers
Material High Density polyethylene(HDPE), PA or other materials.
Color: Black or other colors.
Application ABF has been used indoors, on ships, outdoors including FTTH or practically anywhere conventional cables are used.
Features
  • Greater flexibility for expansion.
  • Less impact on existing fiber optic connection integrity.
  • Less disruption to business operations.
  • Expansions installed in hours not days.

Fiber Count Cable Dimension (mm) Cable Weight (kg) Tensile (N) Crush (N/10cm) Bending Radius (mm)
Long Term Short Term Long Term Short Term Static Dynamic
1— 6 2.5 5.5 0.15G 0.15G 150 450 10D 20D
7—12 3.0 7.5 0.15G 0.15G 150 450 10D 20D
13—24 4.0 14.5 0.15G 0.15G 150 450 10D 20D
1—36 5.5 28.5 40.0 140.0 150 450 10D 20D
36—72 6.0 36.0 54.0 180.0 150 450 10D 20D
