Specifications
Brand Name :
SINOHONE
Model Number :
GYXTW
Certification :
ISO,CE,UL,ROHS
Place of Origin :
Sichuan,China
MOQ :
2000 METER
Price :
USD0.35~3.6/METERS
Payment Terms :
Western Union, T/T, D/P, D/A, L/C
Supply Ability :
1000 Kilometer/Kilometers per Week
Delivery Time :
5 days
Packaging Details :
2km per wooden reel
Product name :
Waterproof Outdoor Fiber Optic Cable
Packing :
Wooden
Number of Conductors :
≥ 10
Life time :
More than 20 years
Oem factory :
Yes
Application :
Telecommunication
Description

Waterproof Outdoor Fiber Optic Cable ADSS applications Cable Splice Enclosure

Descriptions:

GYXTW fiber optic cable is a type of fiber cable that is widely used in aerial application. This type of fiber cable has been praised due to its exceptional performance in Long Distance Symmetric role. As a matter of fact, GYXTW fiber optic cable plays an important role in the telecommunication industry and it’s highly recommended by many technicians.

Characteristics:


Structure with central tube, parallel steel wire, corrugated steel tape armoring;
Small diameter, lighter, easy installation.
Loose tube material has good hydrolysis resistance performance and high strength;
Excellent moisture, water-blocking perfomance;
Glass yarn strength member improve the mechanical properties, and can also prevent ant bites.
Good mechanical performance and environmental properties.

Applications:


Duct, aerial
Access network, FTTH

Standards:


YD/T901-2009
IEC60794-1

Temperature:


Operating temperature: -40°C~+70°C

Technical Parameter

Fiber Count Diameter(mm) Weight (kg/km) Tensile(N) Crush(N) Bending Radius(mm)
2~12 8.5 75 Long term Short term Long term Short term Static Dynamic
600 1500 300 1000 10D 20D
2~12 9.1 100 1000 3000 1000 300 10D 20D
24 9.5 110 600 1500 300 1000 10D 20D

Note:

  • D refers to the cable diameter;
  • The relevant technical Parameters can be adjusted according to the customer’s demands;
  • The block water way can be adjusted according to the customer’ demands;
  • To design flame resistance, anti-rodent, termite resistant cable according to customer’s demands.
