53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
Specifications
Brand Name :
SINOHONE
Model Number :
GYFTA53
Certification :
ISO9001 CPR FCC CE RoHS
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Application :
Telecommunication,Telecom
Product name :
Direct Burial Armored Fiber Optic Cable
Length :
As required
Oem :
Available
Installation :
Direct burial
Structure :
Loose tube
Operating temperature :
-40℃ to +70℃
Description

GYFTA 53 Direct Burial Outdoor Fiber Optic Cable Armored Fiber Optic Cable Single Mode

Product Detail

GYFTY53 uses a Fiber Reinforced Plastic (FRP) as central strength member to provides anti-electromagnetic interference property. The armored structure protects the cable from rat bite and moisture proof. The tubes (and fillers) are stranded around the strength member into a compact and circular core. Then the cable core is covered with a thin polyethylene (PE) inner sheath, which is filled with jelly to protect it from water ingress. A layer of water-blocking material is applied around the cable core to prevent water ingress. It can be used for duct and direct buried application, suitable for frequent lightning area and anti electric field.

Features

  1. Good mechanical and temperature performance

  2. High strength loose tube that is hydrolysis resistant

  3. Special tube filling compound ensure a critical protection of fibre

  4. Crush resistance and flexibility

The following measures are taken to ensure the cable watertight:

  • Single Fibre Reinforced Plastic as the central strength member
  • Loose tube filling compound
  • 100% cable core filling
  • APL moisture barrier
  • PSP enhancing moisture-proof
  • Water-blocking material

Storing temperature:-40℃ to +70℃

Operating temperature:-40℃ to +70℃

Bending radius: Static 12.5×D

Dynamic 25×D

Item Direct Burial Outdoor Fiber Optic Cable GYFTA-53
Picture 53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
Operating Temperature -40℃ to +70℃
Sheath Material Water-blocking material
Tube High strength loose tube

53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof53 Direct Burial Armored Fiber Optic Cable Single Mode Moisture Proof
