Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
Specifications
Brand Name :
SINOHONE
Model Number :
Adapter
Certification :
RoHS ISO9001 CPR FCC CE
Place of Origin :
Sichuan, China
MOQ :
1000 piece
Price :
USD $0.36~$0.38 / pieces
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 pieces per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Fiber Optic Adapters / Couplers
Cable :
Single-mode or Multi-mode
Applications :
LAN, CATV, Telecommunication Network
Durability Time :
＞1000
Exchangeability :
<0.2 dB
Operating Temperature :
-40°C~+75°C
Description

Telecommunications LC / SC Fiber optic adapters Couplers In Fiber Optic Patch Cord

Description:

Fiber optic adapters (also called couplers) are designed to connect two fiber optic cables together. They come in versions to connect single fibers together (simplex), two fibers together (duplex), or sometimes four fibers together (quad).

Adapters are designed for multimode or singlemode cables. The singlemode adapters offer more precise alignment of the tips of the connectors (ferrules). It is ok to use singlemode adapters to connect multimode cables, but you should not use multimode adapters to connect singlemode cables. This can cause misalignment of the small singlemode fibers and loss of signal strength (attenuation).

Specification:

Insertion loss < 0.2dB
Repeatability < 0.2dB
Exchangeability < 0.2dB
Retention force 200-600G
Durability Time >1000
Temperature range -40 80 degree Celsius

Application:


Local Area Network
CATV System
Telecommunication Networks
Equipment Test

Parameter Unit LC, SC, FC, ST
SM MM
PC UPC APC PC
Insertion Loss (Typical) dB ≤0.2 ≤0.2 ≤0.2 ≤0.2
Return Loss dB ≥45 ≥50 ≥60 ≥30
Exchangeability dB ≤0.2
Repeatability dB ≤0.2
Durability Time >1000
Operating Temperature °C -40~75
Storage Temperature °C -45~85

Telecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic CableTelecommunications LC SC Fiber Patch Cable , Multimode Duplex 2 Fiber Optic Cable
