Multi Core Outdoor Fiber Optic Cable High Strength Hydrolysis Resistant
Multi Core Outdoor Fiber Optic Cable High Strength Hydrolysis Resistant
Multi Core Outdoor Fiber Optic Cable High Strength Hydrolysis Resistant
Multi Core Outdoor Fiber Optic Cable High Strength Hydrolysis Resistant
Specifications
Brand Name :
SINOHONE
Model Number :
Outdoor Fiber Optic Cable
Certification :
ISO, CE, UL, ROHS
Place of Origin :
Sichuan, China
MOQ :
1 METER
Price :
USD 0.35 ~ 3.6 / METERS
Payment Terms :
Western Union, T/T, D/P, D/A, L/C
Supply Ability :
1000 Kilometer / Kilometers per Week
Delivery Time :
5 days
Packaging Details :
2km per wooden reel
Operating Temperature :
-40~+70℃
Color :
Black
Application :
Cabling System
Product name :
2 / 4 / 6 / 8 / 12 / 16 / 24 Core Outdoor Cable
Life time :
More than 20 years
Packing :
Wooden
Description


2 / 4 / 6 / 8 / 12 / 16 / 24 Core Outdoor GYTA Single Mode Fiber Optical Cable


GYTA is a type of fiber optic cable in stranded loose tube fiber optic cable with compact structure, and the cable jacket is made of strong Polyethylene. High strength loose tube has hydrolysis resistant. Cable filling materials ensure high reliability, and APL makes the cable crush resistant and moisture proof. So, the GYTA has a very good watertight performance. This cable can be used for LAN and WAN backbones, telecom access lines, fibre to business and fibre to the building drop connections, as well as fibre to the home drop and access connections.


Feature

  • Special design to prevent loose tube shrinking
  • Crush resistance,water blocking and flexibility
  • Good mechanical and temperature performance
  • PE sheath protects cable from ultraviolet radiation
  • High strength loose tube that is hydrolysis resistant
  • Tube filling compound to ensure a critical fiber protection


Application

  • CATV
  • Local trunk line
  • Rural communication
  • Computer networks system
  • Aerial & conduit/duct application



Optical Characteristics

G.652G.65550/125 µm62.5/125 µm
Attenuation(+20℃)@ 850 nm ≤ 3.0 dB/km≤ 3.0 dB/km
@1300 nm ≤ 1.0 dB/km≤ 1.0 dB/km
@1310 nm≤ 0.36 dB/km≤ 0.40 dB/km
@1550 nm≤0.22 dB/km≤ 0.23 dB/km
Bandwidth(Class A)@ 850 nm ≥500 MHz·km≥ 200 MHz·km
@1300 nm ≥ 1000 MHz·km≥ 600 MHz·km
Numerical Aperture 0.200 ± 0.015 NA0.275 ± 0.015 NA
Cable Cut-off Wavelength lcc≤ 1260 nm≤ 1450 nm



Technical Parameters

Cable TypeFiber CountTubesFillersCable DiameterCable WeightTensile StrengthCrush Resistance Long/Short TermBending Radius
(Increased by 2 fibers)mmkg/kmLong/Short TermN/100mmStatic/Dynamic
N mm
GYTA-2~6Xn2~6149.280800/1500300/100010D/20D
GYTA-8~12Xn8~12239.280800/1500300/100010D/20D
GYTA-14~18Xn14~18329.280800/1500300/100010D/20D
GYTA-20~24Xn20~24419.280800/1500300/100010D/20D
GYTA-26~30Xn26~30509.280800/1500300/100010D/20D
GYTA-32~36Xn32~36609.7971000/3000300/100010D/20D
GYTA-38~48Xn38~484110.51091090/3000300/100010D/20D
GYTA-50~60Xn50~605010.51091090/3000300/100010D/20D
GYTA-62~72Xn62~726011.51261260/3000300/100010D/20D
GYTA-74~84Xn74~847113.21531530/3000300/100010D/20D
GYTA-86~96Xn86~968013.21531530/3000300/100010D/20D
GYTA-98~108Xn98~1089114.61821820/3000300/100010D/20D
GYTA-110~120Xn110~12010014.61821820/3000300/100010D/20D
GYTA-122~132Xn122~13211116.52212110/3000300/100010D/20D
GYTA-134~144Xn134~14412016.52212110/3000300/100010D/20D
GYTA-146~216Xn146~216 16.52222220/3000300/100010D/20D
