Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
Specifications
Brand Name :
SINOHONE
Model Number :
GYFTY
Certification :
CPR FCC CE RoHS ISO9001
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Bulk Outdoor Fiber Optic Cable
Application :
Duct,Network
Type :
Outdoor Optical Cable Aerial
Fiber count :
2~120 fibers
Length :
2km or customized length
Oem :
Available
Installation :
Aerial & Duct
Sheath material :
PE
Description

Anti-electromagnetism GYFTY Duct and Non Self-Supporting Bulk Outdoor Fiber Optic Cable

Main Features:

  1. Low coefficient of attenuation and chromatic dispersion.

  2. Small diameter.

  3. Lightweight.

  4. It occupies little space.

  5. Anti-electromagnetism ability.

  6. You can use aluminum or steel tape.

Optical Characteristics

Attenuation @850nm ≤3.0 dB/km ≤3.0 dB/km
(+20℃) @1300nm ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km ≤0.40 dB/km
@1550nm ≤0.22 dB/km ≤0.23dB/km
@850nm ≥500 MHz·km ≥200 MHz·km
Bandwidth (Class A) @1300nm ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm ≤1480nm

Technical Parameters

Cable Type Fiber Count Tubes Fillers Cable Diameter Cable Weight kg/km Tensile Strength Crush Resistance
Bending Radius
Long/Short Term Static/Dynamic
mm Long/Short Term N N/100mm mm
GYFTY-2~6 2~6 1 5 10.6 88 400/1000 300/1000 10D/20D
GYFTY-8~12 8~12 2 4 10.6 88 400/1000 300/1000 10D/20D
GYFTY-14~18 14~18 3 3 10.6 88 400/1000 300/1000 10D/20D
GYFTY -20~24 20~24 4 2 10.6 88 400/1000 300/1000 10D/20D
GYFTY-26~30 26~30 5 1 10.6 88 400/1000 300/1000 10D/20D
GYFTY-32~36 32~36 6 0 10.6 88 400/1000 300/1000 10D/20D
GYFTY-2~6 2~6 1 6 11 97 600/1500 300/1000 10D/20D
GYFTY-8~12 8~12 2 5 11 97 600/1500 300/1000 10D/20D
GYFTY-14~18 14~18 3 4 11 97 600/1500 300/1000 10D/20D
GYFTY-20~24 20~24 4 3 11 97 600/1500 300/1000 10D/20D
GYFTY-26~30 26~30 5 2 11 97 600/1500 300/1000 10D/20D
GYFTY-32~36 32~36 6 1 11 97 600/1500 300/1000 10D/20D
GYFTY-38~42 38~42 7 0 11 97 600/1500 300/1000 10D/20D
GYFTY-44~48 44~48 4 2 12 113 600/1500 300/1000 10D/20D
GYFTY-50~60 50~60 5 1 12 113 600/1500 300/1000 10D/20D
GYFTY-62~72 62~72 6 0 12 113 600/1500 300/1000 10D/20D
GYFTY-2~6 2~6 1 7 12 120 1000/3000 300/1000 10D/20D
GYFTY-8~12 8~12 2 6 12 120 1000/3000 300/1000 10D/20D
GYFTY-14~18 14~18 3 5 12 120 1000/3000 300/1000 10D/20D
GYFTY-20~24 20~24 4 4 12 120 1000/3000 300/1000 10D/20D
GYFTY-26~30 26~30 5 3 12 120 1000/3000 300/1000 10D/20D
GYFTY-32~36 32~36 6 2 12 120 1000/3000 300/1000 10D/20D
GYFTY-38~42 38~42 7 1 12 120 1000/3000 300/1000 10D/20D
GYFTY-44~48 44~48 8 0 12 120 1000/3000 300/1000 10D/20D
GYFTY-50~60 50~60 5 2 13 137 1000/3000 300/1000 10D/20D
GYFTY-62~72 62~72 6 1 13 137 1000/3000 300/1000 10D/20D
GYFTY-74~84 74~84 7 0 13 137 1000/3000 300/1000 10D/20D
GYFTY-86~96 86~96 8 0 13.9 154 1000/3000 300/1000 10D/20D
GYFTY-98~108 98~108 9 1 15.3 185 1000/3000 300/1000 10D/20D
GYFTY-110~120 110~120 10 0 15.3 185 1000/3000 300/1000 10D/20

Duct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self SupportingDuct Bulk Outdoor Fiber Optic Cable Anti electromagnetism Non Self Supporting
