2 4 6 Core Inside Fiber Optic Cable Long Distance Corrosion Resistant Water Blocking
2 4 6 Core Inside Fiber Optic Cable Long Distance Corrosion Resistant Water Blocking
Specifications
Brand Name :
SINOHONE
Model Number :
Indoor Optical Cable
Certification :
CE/ROHS/ISO9001
Place of Origin :
Sichuan, China
MOQ :
2000 METER
Price :
USD0.35~3.6/METERS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Supply Ability :
500 Kilometer/Kilometers per Day Ftth Drop Cable
Delivery Time :
5 Days
Packaging Details :
2km per wooden reel
Product name :
2 4 6 Core Ftth Indoor Fiber Optic Drop Cable
Type :
Multi Core
Strength member :
Loose tube stranded/SZ stranded
Application :
FTTH FTTB FTTX Network
Description

2 4 6 Core Ftth Indoor Fiber Optic Cable 1km Price Corrosion Resistant

Quick Details:

Blockcoat provides optical fibers or ribbons with a dry water blocking functionality in cable tubes without the need for gels or yarn. It is especially suited as a dry-dry solution for micro cables, loose tubes and high density cable designs used in outdoor and outdoor/indoor environments to meet European CPR regulations.

Applications:


Military communication system cabling in the fields;
Communication transmission for oil field, mining operations etc.

Characteristic Details:


Right buffer fiber, be striped easily and excellent flame retardant;
Aramid yarn makes the optical fiber cable have excellent performance of flame and tensile strength resistance;
Material of outer sheath shall be corrosion resistant, water-blocking and flame retardant and environment friendly etc.
Not be influenced by electromagnetism due to all dielectric structural design;
Outer sheath of special material TPU is abrasion, cold and high temperature resistance.

Standards:


YD/T1258.4
IEC60794-2-10/21

Working Temperature:


Operating temperature: -40°C~+60°C


Storage, transportation and installation temperature: -5°C~+50°C

Technical Parameters

Fiber Count Nominal diameter (mm) Nominal weight (kg/km) Permitted Tensile(N) Permitted Crush(N) Bending Radius(mm)
Long term Short term Long term Short term Static Dynamic
2 6 32 1000 2000 1000 2000 10D 20D
4 6.2 34 1000 2000 1000 2000 10D 20D
6 6.6 36 1000 2000 1000 2000 10D 20D

Note:


The structural dimensions and materials used can be designed according to the demands of the customers.
