Specifications
Brand Name :
SINOHONE
Model Number :
Mobile Fiber Optic Cable
Certification :
RoHS ISO9001 CPR FCC CE
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Mobile Fiber Optic Cable
Outer Sheath :
TPU
Application :
Military communications
Strength Member :
Aramid Yarn
Fiber Count :
2, 4, 6
OEM / ODM :
Available
Description

2 4 6 Core Fibers Mobile Fiber Optic Cable For Military Communication System Cabling

Characteristics:

Sinohone mobile fiber optic cable has right buffer fiber, can be easily and excellent flame retardant. It is equiped with corrosion resistant, water-blocking, flame retardant abd environment friendly outer sheath.

Aramid yarn makes the optical fiber cable have excellent performance of flame and tensile strength resistance. Its outer sheath of special material TPU is abrasion, cold and high temperature resistance.

Applications:

Military communication system cabling in the fields;
Communication transmission for oil field, mining operations etc.

Standards:

YD/T1258.4
IEC60794-2-10/21

Temperature:

Operating temperature: -40°C~+60°C
Storage, transportation and installation temperature: -5°C~+50°C

Technical Parameters

Fiber Count Nominal diameter (mm) Nominal weight (kg/km) Permitted Tensile(N) Permitted Crush(N) Bending Radius(mm)
Long term Short term Long term Short term Static Dynamic
2 6.0 32 1000 2000 1000 2000 10D 20D
4 6.2 34 1000 2000 1000 2000 10D 20D
6 6.6 36 1000 2000 1000 2000 10D 20D

Note:

The structural dimensions and materials used can be designed according to the demands of the customers.
