Duct Installation Air Blown Fiber Cable Single Mode Multi Mode 12 Cores
Duct Installation Air Blown Fiber Cable Single Mode Multi Mode 12 Cores
Duct Installation Air Blown Fiber Cable Single Mode Multi Mode 12 Cores
Duct Installation Air Blown Fiber Cable Single Mode Multi Mode 12 Cores
Specifications
Brand Name :
SINOHONE
Model Number :
ABF
Certification :
CPR FCC CE RoHS ISO9001
Place of Origin :
Sichuan, China
MOQ :
2000 meters
Price :
USD $0.38~$0.58 / meter
Payment Terms :
L/C, D/P, T/T, D/A, Western Union, MoneyGram
Supply Ability :
500000 meters per month
Delivery Time :
5-8 work days
Packaging Details :
Standard packing in sealed box or according to customers' requirements
Product Name :
Air-blown fiber optical cable
Material :
LSZH
Color :
Black
Install :
Duct, Aerial
Fiber Count :
1 ~72 Fibers
Cable Diameter :
2.5 mm ~ 6 mm
Fiber Type :
g652d g655c g657a
Armor :
Fiber Yarn
Description

Duct Installation Single Mode Multi Mode 12 Cores Air Blown Fiber Optic Cable

Description

GCYFY is a kind of air blown fiber optic cable, also known as jetting or air-assisted fiber optic cable. It offers reduced cost, increased design flexibility

Air-blown fiber (ABF) is an ideal solution for time-critical and/or challenging data cable installations.​ It also reduces future expansion costs and installation time by laying a foundation where additional fiber cables are added to an existing containing cable more efficiently.

The fiber are coated with a soft acrylate resin, outer sheath is a thermoplastic that is of low friction. Its surface of the sheath is designed with special grooves, compared to the surface of the traditional optical fiber cable. This cable provides not only the high level of mechanical protection, but also the perfect blowing performance.

Fiber


SM: G652D. G655. G657 or other single-mode optical fibers.
MM: Ala. Alb or other multi-mode fibers

Material:

High Density polyethylene(HDPE), PA or other materials.
Color: Black or other colors.

Application:


The kind of cable is suitable for air-blowing installation. ABF has been used indoors, on ships, outdoors including FTTH or practically anywhere conventional cables are used.

Characteristic

  • Lighter and small diameter;
  • Excellent performance of Bending performance;
  • Excellent resistance to lateral pressure, and mechanical and temperature performance.

Air blown fiber offers

  • Greater flexibility for expansion.
  • Less impact on existing fiber optic connection integrity.
  • Less disruption to business operations.
  • Expansions installed in hours not days.

Fiber Count Cable Dimension (mm) Cable Weight (kg) Tensile (N) Crush (N/10cm) Bending Radius (mm)
Long Term Short Term Long Term Short Term Static Dynamic
1— 6 2.5 5.5 0.15G 0.15G 150 450 10D 20D
7—12 3.0 7.5 0.15G 0.15G 150 450 10D 20D
13—24 4.0 14.5 0.15G 0.15G 150 450 10D 20D
1—36 5.5 28.5 40.0 140.0 150 450 10D 20D
36—72 6.0 36.0 54.0 180.0 150 450 10D 20D

Duct Installation Air Blown Fiber Cable Single Mode Multi Mode 12 Cores
