P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm
P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm
P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm
P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm
Specifications
Brand Name :
NIYAKR
Model Number :
P8
Certification :
CE,ROHS,EMC,UL,ISO
Place of Origin :
Shenzhen,China
MOQ :
1 Square Meter
Price :
USD
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20000 Square Meters Per Month
Delivery Time :
12-18 Working Days
Packaging Details :
Wooden Case
Product Name :
P6 Outdoor LED Advertising Screen
Pixel pitch :
6mm
Physical density :
15625 dots/sqm
Use environment :
Outdoor
Color :
RGB Full Color
Cabinet size :
W960m×H960mm
Brightness :
≥6000cd
Waterproof :
IP65
Description

P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm

Led Display Features:

1. Outdoor HD LED Display Leader
Outdoor HD LED Display leader, mature product, functions two years ahead of competitors, worldwide fantastic projects. Core tech fixed series standard modules help clients upgrade to better resolution. Increase the chance to have the second sales and enhance the relationships with clients.

2. Protection Rate IP65 and Module Style Design
Protection rate IP65, installation without frame. Module style design, fast installation and easy maintenance with low cost.

3. No Distortion, Power and Control System Back-up Technology
Deep black surface, firm & flat, anti-UV mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.

Application Places:
Ideal for outdoor advertisement media, government& enterprise project, culture & tourism, sports, propaganda image, commercial real estate.

Technical Specification

Item P6mm outdoor led display
Color Full-color real pixels
Use environment Outdoor
Pixel pitch 6mm
Module size 192*192mm
Physical density 15625 dots/sqm
Pixel configuration 1R1G1B
LED chip SMD3535
Module resolution 40*40
Module power 100w
Recommended viewing distance >5m
Best viewing angle H: 140°; V:120°
Maximum power consumption 980w
Average power consumption 390w
Cabinet size W960m×H960mm
Standard cabinet resolution 120*120
Weight 38kg/cabinet (aluminum) 46kg/cabinet (Iron)
Driving method 1/8 Scan, Constant Current
Video frame rate ≥60 Hz
Rate refresh ≥1920Hz
White balance brightness ≥6000cd
Operating temperature/Humidity -30℃~+45℃
Ingress protection Front:IP 67; Back:IP65
Input voltage 110-220V AC±10%
Gray scale /Color Display Colors ≥281 Trillions (Synchronize)
Brightness control Manual/Automatic
Input signal RF,S-VIDEO,RGBHV,YUV,YC & COMPOSITION,etc
Control system PCTV+DVI video card+control card+fiber
MBTF >500 hours
Life time >100,000 Hours
The rate <0.0002

P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm

P6 RGB Full Color Led Display Outdoor Advertising Video Wall 15625 Dots/sqm
