Specifications
Brand Name :
NIYAKR
Model Number :
P7.62
Certification :
CE,ROHS,EMC,UL,ISO
Place of Origin :
Shenzhen,China
MOQ :
1 Square Meter
Price :
USD
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
20000 Square Meters Per Month
Delivery Time :
10-15 Working Days
Packaging Details :
Wooden Case,Flight Case
Product Name :
Indoor led billboard display
Pixel density :
17222dots/m2
Color :
RGB full color
Working humidity :
10%-90% RH
Control System :
NovaStar,Linsn
Life Span :
≥100,000hours
Description

RGB P7.62 Indoor Advertising LED Display Screen Full Color 17222 Dots/m2

Product Description

Item Parameter
Product model P7.62-8S
Module size 244mm*244mm
Pixel pitch 7.62mm
Pixel density 17222dots/m2
Pixel configuration smd 3in1
Module resolution 32dots(W)*16dots(H)
Maximum power consumption 150W
Module thickness 15mm
Module weight 0.45kg
Driving method Constant current driving
Scan mode 1/8 scan
Interface type HUB 75
Brightness ≥ 1700cd/m2
The specifications of cabinet
Cabinet size 976mm*976mm
Module quantity 16pcs
Power supply 5V/40A 5V/60A 5V80A
Cabinet resolution 128*128dots
Optimal viewing distance 8m ~ 50m
Optimal viewing angle 160°(W) 120°(H)
System operating humility 10%-95%
The specifications of power supply
Operating voltage AC220V±10%
Average power consumption 280W/ m2
Maximum power consumption ≤ 400W/ m2
Current ≤20mA(single LED)
The specifications of control system
Computer Pentium4 or above
Operating system WIN98/2000/NT/XP
Control model Synchronization control
The specifications of the main technical parameters
Driving device Constant current driving
Refresh rate ≥1920Hz
Grey scale RGB each 256 grade, can display 16.7M colors)
MTBF ≥100,000hours
Power switch Automatic switch
Display mode 800*600/1024*768

RGB P7.62 Indoor Advertising LED Display Screen Full Color 17222 Dots/m2

RGB P7.62 Indoor Advertising LED Display Screen Full Color 17222 Dots/m2
