Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
Specifications
Brand Name :
CWD
Model Number :
CWD-HW185LD-F
Certification :
CE/CCC/FCC/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1
Application :
Outdoor
Viewing Angle :
89/89/89/89
Pixel Pitch :
0.4902x0.4902 (HxV)
Contrast Ratio :
1000 : 1
Description

Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone

Quick Details

Place of Origin:Guangdong, China

Brand Name:CWD

Model Number:CWD-HW185LD-F

Type:TFT

Application:Outdoor

Viewing Angle:89/89/89/89

Pixel Pitch:0.4902x0.4902 (HxV)

Contrast Ratio:1000 : 1

Brightness:2500 nits

Response Time:5ms

Input Voltage:100V-240V

Warranty:1 Year

After-sales Service Provided:Video technical support, Online support

Product name:small LCD display

Installation:Floor Standing

Panel brand:LG, Samsung, AUO, BOE, Chimei, Sharp

Material:Metal Case + Toughened Glass Panel

Optional function:Remote control, Touch, Camera, WiFi, 4G etc

Operation System:Android/Windows 7/8/10

Integration:Printer, Scanner, RFID, NFC, Camera, Keyboard etc

Color:Black, White, Red, Green, Charcoal Grey...

Certificate:CE/CCC/FCC/ROHS/ISO9001

PANEL

 Panel Type A+ TFT-LCD Panel 18.5 inch
Active Area 409.8*230.4 mm
Max Resolution 1366*768
Aspect Ratio 16:9
Contrast Ratio 1000:1
Displaying Color 16.7M 68% (CIE1931)
View Angle 89/89/89/89
Response Time ≤5ms
S-system PAL / NTSC / SECAM
Backlight Patented LED module + Constant power components
Brightness 1000 nits - 3000 nits Sunlight readable
Life Expectance ≥60000 Hours

ENVIRONMENT

 Working Temperature -35℃ to 55℃
Storage Temperature -45℃ to 60℃
Working Humidity 5% to 95%
Storage Humidity 5% to 95%

FUNCTION

 Video Format MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB
Image Format JPG,BMP,PNG,TIF,ICO,GIF,TGA
Audio Format MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE
Log Management Supportive to terminal log and playlist log
Power Mode Time-setting On or Off | Manual

HARDWARE

 Material cold-rolling metal plate + Special outdoor powder paint
Protective Glass AR Laminated and Tempered glass (6-8mm)
Heat Dissipation Industrial Fan-cooling | Industrial Air-conditioner
Protective Level IP55 | IP65
I/O Interface DP, HDMI, VGA, DVI, RJ-45, WIFI, 4G, USB, SD Card
Play Mode Plug and play, Network(Remote), Touch
Speakers 2*10W Stereo
Dimension To be customized
N.W / G.W To be customized
Accessories Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card
Certificates ISO9001/CCC/CE/FCC/RoHS/IP65

POWER

 Voltage AC 100V - 240V 50Hz - 60Hz
Consumption ≤ 800W (Due to heat-control system)
Standby ≤ 3W

Urhealth 18.5 inch floor standing small transparent touch screen LCD display with telephone
