Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
Specifications
Brand Name :
CWD
Model Number :
CWD-HW550BG-F
Certification :
CE/CCC/FCC/ROHS/ISO9001
Place of Origin :
Guangdong, China
MOQ :
1
Material :
Metal Case + Toughened Glass Panel
Optional function :
Remote control, Touch, Camera, WiFi, 4G etc
Operation System :
Android/Windows 7/8/10
Integration :
Printer, Scanner, RFID, NFC, Camera, Keyboard etc
Color :
Black, White, Red, Green, Charcoal Grey...
Description

Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness

PANEL

 Panel Type A+ TFT-LCD Panel 55 inch
Active Area 1209.6 x 680.4 mm (W*H)
Max Resolution 1920x1080
Aspect Ratio 16:9
Contrast Ratio 1400:1
Displaying Color 16.7M 68% (CIE1931)
View Angle 178°(H) / 178°(V)
Response Time ≤5ms
S-system PAL / NTSC / SECAM
Backlight Patented LED module + Constant power components
Brightness 1000 nits - 3000 nits Sunlight readable
Life Expectance ≥60000 Hours

ENVIRONMENT

 Working Temperature -35℃ to 55℃
Storage Temperature -45℃ to 60℃
Working Humidity 5% to 95%
Storage Humidity 5% to 95%

FUNCTION

 Video Format MP4,3GP,MPG,AVI,WMV,FLV,SWF,RMVB,MKV,VOB
Image Format JPG,BMP,PNG,TIF,ICO,GIF,TGA
Audio Format MP3,WMA,AMR,OGG,AAC,WAV,FLAC,APE
Log Management Supportive to terminal log and playlist log
Power Mode Time-setting On or Off | Manual

HARDWARE

 Material cold-rolling metal plate + Special outdoor powder paint
Protective Glass AR Laminated and Tempered glass (6-8mm)
Heat Dissipation Industrial Fan-cooling | Industrial Air-conditioner
Protective Level IP55 | IP65
I/O Interface DP, HDMI, VGA, DVI, RJ-45, WIFI, 4G, USB, SD Card
Play Mode Plug and play, Network(Remote), Touch
Speakers 2*10W Stereo
Dimension To be customized
N.W / G.W To be customized
Accessories Remote Control, AC Power Cord, Key, Rack, Instruction, Approval Certificate, Warranty Card
Certificates ISO9001/CCC/CE/FCC/RoHS/IP65

POWER

 Voltage AC 100V - 240V 50Hz - 60Hz
Consumption ≤ 700W (Due to heat-control system)
Standby ≤ 3W

Quick Details

Place of Origin:Guangdong, China

Brand Name:CWD

Model Number:CWD-HW550BG-F

Type:TFT

Application:Outdoor

Viewing Angle:178(H)/178(V)

Pixel Pitch:0.630x0.630 mm (HxV)

Contrast Ratio:1400:1

Brightness:2500 nits

Response Time:5ms

Input Voltage:100V-240V

Warranty:3 years, 3 Years

After-sales Service Provided:Video technical support, Free spare parts, Online support

Product name:big screen outdoor tv

Installation:Wall-mount; Ceiling-mount, Embedded, Hanging

Panel brand:LG, Samsung, AUO, BOE, Chimei, Sharp

Material:Metal Case + Toughened Glass Panel

Optional function:Remote control, Touch, Camera, WiFi, 4G etc

Operation System:Android/Windows 7/8/10

Integration:Printer, Scanner, RFID, NFC, Camera, Keyboard etc

Color:Black, White, Red, Green, Charcoal Grey...

Certificate:CE/CCC/FCC/ROHS/ISO9001

Urhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightnessUrhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightnessUrhealth waterproof lcd wall-mounted billboard advertising display with touch screen high brightness
