P5 Advertising LED Display Screen , Indoor SMD LED Display High Efficiency Luminescence
P5 Advertising LED Display Screen , Indoor SMD LED Display High Efficiency Luminescence
Specifications
Brand Name :
ABT
Model Number :
P5
Certification :
FCC,CE,UL,ROSH,ISO9001
Place of Origin :
Shenzhen,China
MOQ :
1square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1500square meter/month
Delivery Time :
7-15days
Packaging Details :
wooden case;flight case
Module size :
320*160mm
Driving mode :
constant driving 1/16
Led type :
SMD2121
Brightness :
2300cd/sqm
name :
p5 indoor LED display
Screen dimension :
Customized
Description

High Quality SMD LED Display Indoor P5 Perfect Effect Screen

For indoor products:

The indoor display uses high-quality LED, which has high efficiency luminescence,decreased attenuation of brightness,high stability and reliability. Super uniformity in color. Low-budget,high pixel density,more vivid and stable pictures(No Flickering). The ultra-slim and ultra-lightweight structure,increased design opportunities and lower transportation costs.

SMD technology takes super wide viewing angle for the LED display; better color performance, higher contrast ratio and higher refresh rate. The Slim Indoor LED Display features low weight,special rigging system for simplified service,hassle-free mounting, easy configuration and maintenance,and several other enhancements that are unmatched in the industry.
Including: PH2.5,PH3, PH4, PH5, PH6, PH7.62, PH8, PH10.

Specifications:

Technical parameters
S/N Module Specification
1 Pixel Pitch 5mm
2 Pixel Configuration 1R1G1B
3 LED Type SMD2121
4 Pixel Density 40000 pixel dots/s.q.m
5 Module Size(W X H) 320mm x 160mm
6 Module Resolution( W X H) 64 pixel dots x 32 pixel dots
7 Input Voltage(DC) 5V +/- 5%
8 Cabinet Specification
9 Cabinet Size(W X H) 960mm x 960mm
10 Cabinet Resolution(W X H) 192pixel dots x 192 pixel dots
11 Unit Cabinet Weight 30kg(without packaging)
12 Whole Screen Specification
13 Screen Brightness Min. 1700nits/s.q.m
14 Driving Mode Constant current 1/16 driving
15 H/V Visual Angle 140deg./70deg.
16 Minimum Viewing Distance 5m
17 Max. Power Consumption 850W/s.q.m
18 Average Power Consumption 700W/s.q.m
19 Gray Level 4096 levels
20 Blind Spot Rate Max. 1/10000
21 Power Supply Mode AC220 +/- 10% 50Hz/AC110 +/- 10% 60Hz
22 Environment Temperature & Humidity Temperature -20 Celsius degree~+60 Celsius degree
Humidity 10%~90% RH
23 Control System
24 Operating Environment Operating system
Chinese/English Windows98/me/2000/NT/XP
Hardware Configuration
Pentium 300MHz or above
ROM 64M
Graphics Card Standard VGA 256mode or above
Related Software
Microsoft Media player compulsory
OFFICE2000 in case of *. doc files
RealPlayer in case of RealPlayer files
25 Software LED Studio
26 Control Mode Synchronization display(work with computer)
27 Control System DVI video card + full color control card + fiber system( optional)
28 Display Content Video DVD, VCD, TV, image, texts.etc.
29 Interface Standard Ethernet
30 Transmission Distance CAT5 cable:<100 m; Single fiber:<10 km

After-Sales Service

1) Training after order
After the order is placed, a processional training will be offered, including software use, operate safety, maintain equioment.

2) Installation and debugging
We could send professionals to conduct on site installation and debugging in strict.

3) Warranty
Warranty: 2 years warranty, lifetime maintenance equip with free spare parts. The first 2 years after shipment, we will be responsible for free maintenance if any problem caused by quality itself. While you should take the cost of the freight to us. After 2 years, service is still available, but would charge for labor, material and freight cost that generates.

4) Maintenance
Maintenance principles: response in time, solve problems asap and ensure the use.
Maintenance period: In the maintenance period of the led display body, free of all maintenance charges.
After maintenance period, only charge the material cost and labor cost.

5) service
Your inquiry ralated to our products or price will be replies in 24hours.
OEM&ODM. any your customized lighting we can help you to design and put into product.
Distributorship are offered for your unique design and some our current models.
Protection of your sales area, ideas of design and all your private information.
Top Quality+Reasonable Price+Responsible After Service=Successful&Win
