High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
High Resolution P4 Full Color LED Panel , HD P4 RGB LED Display Board
Specifications
Brand Name :
ABT
Model Number :
P4
Certification :
FCC,CE,UL,ROSH,ISO9001
Place of Origin :
Shenzhen,China
MOQ :
1square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1500square meter/month
Delivery Time :
7-15days
Packaging Details :
wooden case;flight case
Module size :
256*128mm
Driving mode :
constant driving 1/16
Led type :
SMD2121
Brightness :
3000cd/sqm
Tube chip color :
full color
name :
indoor full color LED display screen
Description

Indoor full color SMD P4 High Definition LED display screen

Product features:

1) High and adjustable brightness can meet the demands of the changing requirement of Customer in different environments.

2) No mosaic due to excellent flatness and nice uniformity of light-emitting.

3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.

4) Good heat dissipation capability because of the unique design of vent fan (liking shutter).

5) Environmental-friendly and energy-saving.

Specifications:

List Item Description
1 Pixel Pitch 4mm
2 Module Size 256*128mm
3 Pixel Density 62500/s.q.m
4 Pixel composition 1R1G1B
5 LED Type SMD2121
6 Module Resolution 64*32
7 Power Consumption of Module 30W
8 Standard Cabinet Size 1024*1024mm
9 Cabinet Resolution 256*256
10 Cabinet Weight 40Kg
11 Driving IC MBI5124GP
12 Driving Method 1/16 Scan Constant Current Driving
13 White Balance Luminance(CD/s.q.m) ≥1500cd/s.q.m
15 Operating Environment Temperature -20℃—60℃ Optional
16 Operating Voltage 220V±10% or 110V±10%
17 Grey Scale Display Colors≥65.7trillion color(Synchronized)
18 Brightness Adjustment 1024 grades of each color(R.G.B)can be adjusted manually and 16 levels of each color can be adjusted automatically
19 Input Signal RF,S-Video RF, S-Video, RGB, RGBHV, YUV
20 Control System PC+ DVI display card+ sent card+ receive card

FAQ:

1. Are you factory?

Yes, we have very rich experience in production and development. you will got better service and delivery on time.

2. How is your delivery time?

We delivery as contract on time, All kinds of led module have in stock. We will be fine as compensation.

3. What is your products packing?

We provide 3 kinds of packing case: carton paper case,wooden packing case and flight packing case.

Carton paper case for led module

Wooden packing case for heavy iron cabinet

Flight packing case for rental aluminum die-casting cabinet

4. Quality gurantee:

Life span of LED display screens is more than 100,000 hours

All our LED displays have CE,FCC,RoHS certificates.

5. Prompt &Professional service :

Any inquires will be replied within 24 hours in working days and you’ll get helpful suggestions from us.
