Easy Maintain Waterproof LED Display , P8 SMD 3535 Outdoor Full Color LED Panel
Easy Maintain Waterproof LED Display , P8 SMD 3535 Outdoor Full Color LED Panel
Specifications
Brand Name :
ABT
Model Number :
P8
Certification :
FCC,CE,UL,ROSH,ISO9001
Place of Origin :
Shenzhen,China
MOQ :
1square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1500square meter/month
Delivery Time :
7-15days
Packaging Details :
wooden case;flight case
Module size :
256*128mm
name :
outdoor full color LED display
Led type :
SMD3535
Brightness :
7000cd/sqm
Tube chip color :
full color
Screen dimension :
Customized
Description

Waterproof advertising P8 outdoor full color led panel

Product Description

1. The pixel is tall, the quality is exquisite and realistic, the color is pure and thick.
2. The flatness is good and the picture is uniform and pleasing to the eye.
3. High grayscale and high refresh, the studio video effect is realistic.
4. Safety performance structure, enhanced design is not easy to deform.
5. Large-angle imaging display technology to meet the wide range Angle to view unbiased color.
6. Easy to maintain.

Specification

Outdoor Full Color P8 LED Display
Main Model P8-4S
Module Pixel pitch(mm) 8
LED Lamp Model SMD3535
Module Size(W*H) 256*128mm
Module Size(W*H) 12.6*6.3inch
Module Resolution(W*H) 32*16
Driving Mode Constant drive
Scan Mode 1/4
Pixel configuration (R,G,B) SMD3in1
Color temperature (K) : 3200-9300
Grey scale/colors 256levels of each color(RGB)/28.1M colors
Cabinet Standard Cabinet Size(mm) 1024*1024
(W*H)
Cabinet Resolution(W*H) 256*256
Cabinet Module Number 8PCS
IP Grade IP65
Cabinet Weigh(kg) 45
Cabinet Material Iron
Display Best Viewing Distance(m) 8-50
Pixel Density (dot/m2) 15625
Brightness(cd/m2) ≥7000
Power Max Consumption (W/m2) ≤800
Power Average Consumption (W/m2) 400
View angle H:160; V:120
system Specification Control host (CPU) : Pentium4 or above
Operating system: WIN98/2000/NT/XP
Control method Synchronous display with control PC by DVI
Control System Linsn, Nova-star, Colorlight or as you required
Display Content Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc.
Interface definition HUB75
Frame Frequency ≥60Hz
Refresh frequency 4000HZ
Transmission Distance Multi mode fiber
Operation Parameter Working Voltage AC220±10% 50Hz/AC110±10% 60Hz
storage Temperature 35℃~+85℃
Working Temperature 20℃~+50℃
Humidity 10%-90%
Life Span Time ≥100000 hours
MTBF ≥5,000hours
Screen Plainness
Blind Spot Rate
Certificate CE, RoHS, FCC


Easy Maintain Waterproof LED Display , P8 SMD 3535 Outdoor Full Color LED Panel

After-sale service
1. Our products have two years warranty service ,lifetime free maintenance and upgrade.
2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
3. We offered training to our customer who includes operating and maintenance of our products.
4. In the Maintenance period of the LED screen body, free of all maintenance charges; After Maintenance period, only charge the material costs fees free of manual work fees.
5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
6. If the users find any problem that cannot be solved, please contact with our company, we can response in 24 hours. In order to shorten the maintenance time, Our Company will deploy some spare parts such as power and chips etc.
