Specifications
Brand Name :
ABT
Model Number :
P4
Certification :
FCC,CE,UL,ROSH,ISO9001
Place of Origin :
Shenzhen,China
MOQ :
1square meter
Price :
Negotiation
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
1500square meter/month
Delivery Time :
7-15days
Packaging Details :
wooden case;flight case
Module size :
256*128mm
Driving mode :
constant driving 1/16
Led type :
SMD2121
name :
p4 indoor LED display
Tube chip color :
full color
Screen dimension :
Customized
Description

High refresh P4 indoor full color led video display

Product Function and Technology Character

1. SMD 3-in-1 LED guarantee wide viewing angle and great color uniformity

2. High definition guarantee excellent performance

3. Idea for use at indoor locations with short & middle viewing distance

Module Parameter:

Pixel pitch 4mm
Pixel configuration 1R1G1B
LED type 3-in-1 SMD 2121
Module size 256*128mm
Module weight 219g
Module resolution 64*32 dots
Module quantity per cabinet 32pcs

Cabinet Parameter:

Cabinet size 1024*1024mm
Cabinet material Iron cabinet
Cabinet weight 35kg+/-0.05kg
Cabinet resolution 256*256dots
Ingress protection Front/Rear IP65/IP54
Whole Screen Parameter
Pixel density 62500 dots/
Brightness ≥1500 cd/
Viewing angle H≥160° V≥120°
Min.viewing distance 4m
Max.power consumption 900W/
Avg.power consumption 400 W/
Working voltage 110~220VAC±15%
Interface HUB75
Colors 16.7millon colors
Gray level 14-16bits
Frame frequency ≥60frames/s
Refresh rate ≥60Hz
MTBF ≥5000 hours
Lifespan ≥100000 hours
Protective function

Over-heat/Over-load /Power-down /Power-leakage

/Lightning-protection etc.

Operating temperature -10℃ ~ +40℃
Operating humidity 10-80% no condensation
Storage temperature -20℃ ~ +60℃
Storage humidity 10-85% no condensation

Control System Parameter:

Video signal (with video processor) AV, S-video,VGA, DVI, YPbPr, HDMI, SDI, DP
Color temperature Adjustable by software
Brightness level 256 levels, automatic adjustment by software
Control way Computer, video-synchronous, real-time, off-line, wireless, inter

OUR PRINCIPLE


1. Company Goals:Spare no effort to create a century enterprise in the field of LED display and semiconductor lighting industry.
2. Spirit of enterprise:Professionalism, Integrity, Teamwork, Innovation
3. Enterprise Mission:Developing leading technology,creating bright environment, sharing brilliant life
4. Business strategy:Joint professional talents, Produce the best products, Provide the best service
5. Enterprise strategy:Switching from the enterprise of products researched and produced to the pilot by expanding strategy,which means the LED products for the center,integrating other electronic low carbon, energy-saving,pro-environment products comprehensive exploited,we become architects of the new social and new life.

FAQ


1:What is the warranty of your led display?
A:We offer 2years warranty.and more than 100000 hours screen life span


2:Can it play HD video?
A:Yes,it have HD video function with Novastar controlling system.


3:what is your payment term?How long it takes to delivery?
A:We usually accapt the T/T or L/C.both of them will at least 30% deposit in advance,and the rest of 70% will paid before delivery.The lead time is usually 20 days


4:How can you ensure the led display product quality?
A:Before shippment,all the screens have aging test.and then we also have waterproof test and shake test,ensure products can transportation safety and normal use.


5:What is your pre-sale and post-sale service?
A:For pre-sale service,we have professional sales team and technical team,who are willing to answer your question within 24 hours.
For post-sale service,we will instruct you how toinstallation,how to use,how to change the broken moudles,and we can also send the technicals to your country,in general,our led display will not have a big problem,you can rest assured to buy.


6:How to choose suitable led display?
A:Please offer size about width and height,for outdoor fix led display,it would be more better to offer installation height and viewing distance,we will recommend suitable led display for your project.We will more appreciate you can offer photos of screen location.
