High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz
Specifications
Brand Name :
King VisionLed
Model Number :
P10
Certification :
CE, ROHS, ISO 9001, UL
Place of Origin :
Guangdong, China
MOQ :
6 Square Meters
Price :
$510.00/Square Meters 6-49 Square Meters
Payment Terms :
D/A, D/P, T/T, Western Union, L/C, MoneyGram
Supply Ability :
1000 Square Meter/Square Meters per Week
Delivery Time :
15 working days
Packaging Details :
Flight case:530mmx650mmx1000mm, 6 pcs panels or 8 pcs panels packed in 1 flight case
Application :
Outdoor building / gymnasium / real estate/
Name :
Advertising LED Display Screen
Life time :
100000hours
Working temperature :
-30 ° C to + 50 ° C
Driving Method :
1/4 scan
Viewing Angle (Vertical / Horizontal) :
120° / 120°
Description

Outdoor Led Billboards P6 P8 P10 6500 High Brightness IP65 Nationstar 1920-2880Hz

Our Service of Outdoor Advertising LED Display Screen of Our advantages:
1, Pixel Pitch: 10mm.
2, SMD, Wide viewing angle: 160°/ 160°.
3, Full color, 281trillions.
4, IP rating: front: IP65/ rear: IP54.
5, 3years warranty.
6, Recommended minium viewing distance: 10m.

Outdoor Advertising LED Display Screen P4 P5 P6 P8 P10
Pixel Pitch(mm) 4 5 6.67 8 10
LED Chips SMD1921 SMD2525 SMD3535 SMD3535 SMD3535
Pixel density(dots/m2) 62500 40000 22477 15625 10000
Driving Method 1/10 scanning 1/8 scanning 1/6 scanning 1/5 scanning 1/2 scanning
Module Size(mm) 320*160 320*160 320*160 320*160 320*160
Module Resolution 80*40 64*32 48*24 40*20 32*16
Cabinet Size( W*L mm) 960*960 960*960 960*960 960*960 960*960
Cabinet Material

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy

Magnesium

Alloy
Cabinet Weight( Kg/m2 ) 35 35 35 35 35
Max.Consumption(W/m2) 800 800 800 800 800
Ave.Consumption(W/m2) 350 350 350 350 350
Brightness( Nits ) ≥5500 ≥5000 ≥5500 ≥5800 ≥6000
Viewing Angle (Vertical / Horizontal) 120° / 120° 120° / 120° 120° / 120° 120° / 120° 120° / 120°
Refresh Rate ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz ≥1920Hz
IP Level IP65 IP65 IP65 IP65 IP65

Application:

The size of the Outdoor LED Screen displays and LED signs are very important to know to determine the resolution per square meter (or per square feet) we have to set for the screen. This is to avoid low quality video with very little detail or a very high quality video that is not necessary (in some cases it depends on the customer's project type). The variable that decides the LED screen resolution per square meter is called the pixel pitch, which tells us the distance between the LED´s in millimeters. The shorter the distance of the LED´s, the higher the screen resolution per square meter, and a greater distance, the resolution will be less.

In the whole world, which have more than 1000 LED commercial billboards around, those are the success of famous modern cities,Let your imagination fly to Canada, to Sweden, to Spain, to Iraq, fly to Sri Lanka. King visionled can help you determine and develop your outdoor LED commercial advertising project and boost up sales through visual and effective marketing, mass medium and publicity.

High Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880HzHigh Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880HzHigh Brightness Outdoor LED Billboards P6 p8 p10 6500 IP65 Nationstar 1920-2880Hz

FAQ of outdoor led display billboard

Q. How long time is needed to produce? A. Our production time is 3-15 working days.

Q. How long does shipping take? A. Express and air shipping usually take 5-10 days. Sea shipping takes about 15-55 days according to different country.

Q. What trade terms do you support? A. We usually do FOB, CIF, DDU, DDP, EXW terms.

Q. This is the first time to import, I don’t know how to do. A. We offer DDP door to door service, you just need to pay us, then wait to receive order.

Q. Do I need to buy other equipment to install LED screen? A. You just need to prepare structure and installation tools.

Q.What is LED screen common size? A.16:9 and 4:3 aspect ratio is popular.
