P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality
Specifications
Brand Name :
King Visionled
Model Number :
P1.875
Certification :
CE, CCC, Rohs, FCC ISO
Place of Origin :
Guangdong, China
MOQ :
Min 6 Square meter
Price :
USD 1,550.00- 2,000.00/SQM
Payment Terms :
D/P, T/T, L/C, D/A
Supply Ability :
1000 sqm / month
Delivery Time :
15 Working days
Packaging Details :
Carton box, Plywood case or flight case, Single package size is 84X68X38 cm about 50kg
Place :
TV Station,control room,command center etc,
Panel Size :
480x480mmx57mm
Module size :
160mm*160mm
Refresh rate :
3840Hz
Name :
8K LED Video Wall
Installation Type :
Front&Rear installation
Description

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good Quality

8K LED Video Wall Product Description
Refresh rate of led display can be adjusted by software, refresh rate can reach more than 2880 Hz ;
The cabinet is very light, very thin, weighs only 4.6kg / box, the thickness of only 66mm;
HD small spacing, suitable for close viewing ;
4: 3 design of the box specifications, screen body easier to achieve 4: 3 assembly;
Rich color and brightness of the black lamp, have better gray and contrast;

4K 8K LED Video Wall of Technical Parameter

Parameter P1.875mm HD LED Screen P2.5mm HD LED Video wall
Pixel Pitch 1.875mm 2.5mm
Pixel Configuration SMD 3-IN-1 SMD2121 3-IN-1
Pixel Density 284,089 dots/m² 160,000 dots/m²
Module size 240x240mm 240x240mm
Cabinet Size 480x480mmx57mm 480x480mmx57mm
Panel Dimension (WxHxD) 18.9''X18.9''X3'' 18.9''X18.9''X3''
Panel Material Die-casting Aluminum Die-casting Aluminum
Panel Weight 4.9kg/panel (10.8lb/panel) 6.8kg/panel (15lb/panel)
Refresh Rate 1920Hz~3840Hz 1920Hz~3840Hz
Brightness 1000nits(Adjustable) 1200nits(Adjustable)
Horizontal Viewing Angle(°) 160 ° 160 °
Vertical Viewing Angle(°) 160 ° 160 °
AC Power Input(V) AC110V~ 220V ±10% AC110V~ 220V ±10%
AC Power Frequency(Hz) 50 ~ 60 Hz 50 ~ 60 Hz
Max. Power(W/m²) 565 W/m² 520 W/m²
Avg. Power(W/m²) 189 W/m² 170 W/m²
Storage/Operating Humidity(RH ) 10% ~ 90%RH 10% ~ 90%RH
IP Rating(IP ) IP30 / IP30 IP30 / IP30
Lifetime Typical Value(Hrs) 100,000 Hrs 100,000 Hrs
Installation Type Front&Rear installation Front&Rear installation
Maintenance Method Front&Rear Access Maintenance Front&Rear Access Maintenance

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality

Product Details & Application

1.Magnetic Module with frame-sharing 480x480mm die-casting aluminum cabinets

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality

2. Friendly Cabinet design with comfortable rounded corner handle,heat emission holes,signal indicator testing button,OEM Label, Anti-collision corner,Hidden cables design and front maintenance tool design.

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality

3.Free-structure Install, flexible for wall mounted fixed and saving installation cost and space

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality

4.Wide application indoor stage rental or indoor advertising or presentation

P2 HD 1000cd/M2 SMD1515 Indoor 8K LED Video Wall 3840HZ HD 1.875mm Pitch Good quality

Our Services of 4K 8K LED Video WALL

Q1: Can i place a sample order before i decide to do the mass production?
A: Yes, we acceptable sample orders LED WALL, please let us know your detail request then we will send you the sample asap for confirmation

Q2: Can i have a free sample?
A: We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent

Q3: Can we make any size of LED WALL?
A: Nope, according the led module size and cabient size, such as ph4.81mm is 500x500mm for smallest unit.
