Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen
Specifications
Brand Name :
King Visionled
Model Number :
P1.875
Certification :
CE, CCC, Rohs, FCC ISO
Place of Origin :
Guangdong, China
MOQ :
Min 6 Square meter
Price :
USD 1,550.00- 2,000.00/SQM
Payment Terms :
D/P, T/T, L/C, D/A
Supply Ability :
1000 sqm / month
Delivery Time :
15 Working days
Packaging Details :
Carton box, Plywood case or flight case, Single package size is 84X68X38 cm about 50kg
Application :
TV Station,control room,command center etc,
Panel Size :
480x480mmx57mm
Module size :
160mm*160mm
Refresh rate :
3840Hz
Other Name :
8K LED Video Wall
Installation Type :
Front&Rear installation
Description

P1.25 HD 8K LED Video Wall Display Wall Mounted 640000 Dots/M2 Images Dot To Dot Matching

8K LED Video Wall Product Description
Standard cabinet size:600*337.5mm,16:9 aspect ratio. HD video and picture dot to dot matching.
Free splicing into 2K/4K/8K. 27’ single cabinet size is for replacing 54’ and 108’ LCD display. Adopt 64
scan high refresh rate diving IC, smooth and delicate display performance
1,Module size:150x168.75mm, compatible pitch: M1.25/M1.5625.
2,Cabinet size:600x337.5mm,16:9 aspect ratio.
3,Floating connection design between module and cabinet, module could be fine-tuned.
4,Support double backup of power supply and control system.
5,Front access and front service, saving space and cost
Product Specifications

4K 8K LED Video Wall of Technical Parameter

Parameter P1.875mm HD LED Screen P2.5mm HD LED Video wall
Pixel Pitch 1.875mm 2.5mm
Pixel Configuration SMD 3-IN-1 SMD2121 3-IN-1
Pixel Density 284,089 dots/m² 160,000 dots/m²
Module size 240x240mm 240x240mm
Cabinet Size 480x480mmx57mm 480x480mmx57mm
Panel Dimension (WxHxD) 18.9''X18.9''X3'' 18.9''X18.9''X3''
Panel Material Die-casting Aluminum Die-casting Aluminum
Panel Weight 4.9kg/panel (10.8lb/panel) 6.8kg/panel (15lb/panel)
Refresh Rate 1920Hz~3840Hz 1920Hz~3840Hz
Brightness 1000nits(Adjustable) 1200nits(Adjustable)
Horizontal Viewing Angle(°) 160 ° 160 °
Vertical Viewing Angle(°) 160 ° 160 °
AC Power Input(V) AC110V~ 220V ±10% AC110V~ 220V ±10%
AC Power Frequency(Hz) 50 ~ 60 Hz 50 ~ 60 Hz
Max. Power(W/m²) 565 W/m² 520 W/m²
Avg. Power(W/m²) 189 W/m² 170 W/m²
Storage/Operating Humidity(RH ) 10% ~ 90%RH 10% ~ 90%RH
IP Rating(IP ) IP43 IP43
Lifetime Typical Value(Hrs) 100,000 Hrs 100,000 Hrs
Installation Type Front&Rear installation Front&Rear installation
Maintenance Method Front&Rear Access Maintenance Front&Rear Access Maintenance

Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen

Product Details & Application

1.Magnetic Module with frame-sharing 480x480mm die-casting aluminum cabinets

Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen

2. Friendly Cabinet design with comfortable rounded corner handle,heat emission holes,signal indicator testing button,OEM Label, Anti-collision corner,Hidden cables design and front maintenance tool design.

Full Color Indoor Led Video Wall P1.25 P1.875 P2.5 HD Led Display Screen

3.Free-structure Install, flexible for wall mounted fixed and saving installation cost and space

4.Wide application indoor stage rental or indoor advertising or presentation

Our Services of 4K 8K LED Video WALL

Q1: Can i place a sample order before i decide to do the mass production?
A: Yes, we acceptable sample orders LED WALL, please let us know your detail request then we will send you the sample asap for confirmation

Q2: Can i have a free sample?
A: We offer free sample for some models, please advise what you need to see if we have available free samples here to be sent

Q3: Can we make any size of LED WALL?
A: Nope, according the led module size and cabient size, such as ph4.81mm is 500x500mm for smallest unit.
