Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm
Specifications
Brand Name :
King VisionLed
Model Number :
P3.91-7.8
Certification :
CE, CCC, Rohs, FCC ISO
Place of Origin :
Guangdong, China
MOQ :
6 Square Meters
Price :
$685.00/Square Meters 6-49 Square Meters
Supply Ability :
1000 Square Meter/Square Meters per Week
Packaging Details :
Flight case:530mmx650mmx1000mm, 6 pcs panels or 8 pcs panels packed in 1 flight case
Payment Terms :
D/A, D/P, T/T, Western Union, MoneyGram
Delivery Time :
15 working days
Color :
Full color
Pixel Pitch :
3.91-7.8mm
Cabinet size :
customized
Transparency :
55%-72%
Max. Power(W/m2) :
380
Power Supply :
Meanwell/G-energy/YHY
Description
Full Color Super Slim Outdoor Curtain Glass Transparent P2.6-7.82mm Super Bright Flexible Led Panel
Transparent LED Display Screen Frame-less design
The frame-less design getting lighter and more transparent.
The minimum screen pitch of 1.9mm makes the picture more delicate and can achieve 4K HD
Because the screen is transparent, placing it in any environment will not affect the lighting and sight you need.
1000 * 500mm standardized design (shape can be customize.
Transparent LED Display Screen Quick and easy installation
Modular box quick-release connection, reducing tedious installation steps
At the same time reduce the weight of the whole screen. This is one of the key advantages of transparent LED display screen.

Transparent LED Display Screen Specifications
LED Module Color configuration SMD2121/1921 1R1G1B 3 in 1
Pixel Pitch(mm) 3.91x7.81mm 7.81*7.81mm
Module Size(mm) 500(W)× 125(H)
Module Weight(kg) 0.35
Module Max Power(W) 25
Module Quantity(W×H) 2×4
Cabinet Cabinet Resolution(W×H) 256×64 128×64
Cabinet Size(mm) 1000(W)×500(H)×80(D)
Cabinet Weight(kg) ≤6
Pixel Density(Dot/m2) 16384
Transparency 55%-72%
Cabinet Material Die Casting Aluminum
Optical parameter Brightness Control Level 256 degree by software
Brightness Control Mode Automatically/Manul Operation
Brightness at White(nits) ≥800, can be adjusted
Viewing Angel(H/V°) 140/140
Max. Power(W/m2) 380
Ave.Power(W/m2) 190
AC Input AC110~220V10%, 50~60Hz,
Drive Mode 1/16Scan 1/8Scan
Grey Scale 16bits
Refresh rate ≥3840Hz/s,can be adjusted
Life Span >100,000H
Working Temperature,Humidity -20℃~+50℃,

Full Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mmFull Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mmFull Color Super Slim Bright Flexible Led Display Panel Curtain Glass P2.6-7.82mm

Transparent LED Display Screen FAQ:

Q1: How to choose a proper led screen for your need?

A1: You just need to know the answers of 3 simple questions. ❶. Will you use it indoor or outdoor(waterproof and brightness)? ❷. Is it for rental use(need to be moved from one place to another place very often) or for fixed installation( to be installed in one place forever)? ❸. What is the approximate size of the led screen you would like to purchase?

Q2: How to install it after i received it?

A2: We will offer you the drawing to guide you for installation, we could also offer steel drawing, software set up drawing or photo or send our engineer fly to you for help if needed.

Q3: How long could i receive the inquiry reply?

A3: You will get a reply within 24 hours.

Q4: How is the after sales service?

A4: We have a professional team which is in all around the world, also a service hot-line dealing with your voice and feedback. We also offer 24-hour online service to help you solving problems.

Q5: How long is the guarantee period?

A5: All kinds of our LED display screen here we offer 2 years at least warranty.
