High Brightness LCD Open Frame Monitor 21.5 85W Low Power Consumption
High Brightness LCD Open Frame Monitor 21.5 85W Low Power Consumption
Specifications
Brand Name :
High Brightness Open Frame LCD Module
Model Number :
Model：OF215EDCL
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T, Western Union
Delivery Time :
4~5 weeks
Packaging Details :
Pearl cotton shock absorption + carton packaging
Supply Ability :
200 pcs / month
Price :
Negotiable
Panel Type :
a-Si active matrix TFT-LCD
Resolution :
1920 x 1080
Brightness :
2000 nits
Power Consumption :
85W
Description

21.5”High Bright Open Frame LCD Module Model:OF215EDCL

LED Array Backlight Enhanced

Model:OF215EDCL

FEATURES:

Active Matrix TFT-LCD Display

LED Direct Type Backlight Enhanced

High Brightness 2000 nits, Sunlight Viewable

1920 x 1080 Max. Resolution

Aspect Ratio: 16:9 in landscape or portrait mode

Super Wide Viewing Angle 176 deg (L/R)

Wide operating temp range, -20 ～ 50o C option

LVDS (Low Voltage Differential Signaling) Interface

Main Specs of 21.5” High Bright LCD module

PANEL TYPE a-Si active matrix TFT-LCD
ACTIVE AREA 476.64(H) x 268.11(V) mm
NATIVE RESOLUTION 1920 x 1080 RGB, VGA to WUXGA
PIXEL PITCH 0.2482(H) x 0.2482(V) mm
COLOR 16.7 M, 8 bits depth
BRIGHTNESS 2000 cd/m2, LED Backlight Enhanced
CONTRAST RATIO 1000:1, Dynamic contrast ratio: 20000:1
DIMMING Auto-dimming by Light Sensor, 100% to 30%
BLU LIFETIME 40,000 Hours Typical
VIEWING ANGLE 89/89/89/89 L/R/U/D
INTERFACE VGA/HDMI
VIDEO INPUT 0.7Vp-p / 75 ohm, Auto detect NTSC/PAL
RESPONSE TIME 10/6ms Typical(Tr/Td)
REMOTE CONTROL Support for Full OSD Features
OPERATION VOLTAGE 12VDC
POWER CONSUMPTION 85 Watt at Highest Brightness Level
STANDBY MODE 3 Watt or less
ACCESSORIES Remote Controller, HDMI cable
VGA cable x 1

OPERATING

(Option)

Android OS Media Player, 1GDDR, 8G SSD

3G wireless communication

OUTLINE DIMENSION

PANEL WEIGHT

495.6(H) x 292.2(W) x 26(D) mm,

5 Kg approx after Modified
COOLING Fans cooling by temper sensor
ENVIRONMENTAL

Operating Temperature -10-50C,

Wide temp. -20-50C (option)
Operating Humidity 10%-85%
Storage Temperature -30-60C
Storage Humidity 5%-90%
ENCLOSURE IP54 Waterproof Enclosure Option
Iron Sheet Folded front frame and back cover,
Vandal Glass on front, VESA mount
WARRANTY 1-3 Years

High Brightness LCD Open Frame Monitor 21.5

High Brightness LCD Open Frame Monitor 21.5
