86 inch High Brightness Indoor Digital Advertising Display 3840x2160 UHD 2000 nits 1850W
86 inch High Brightness Indoor Digital Advertising Display 3840x2160 UHD 2000 nits 1850W
86 inch High Brightness Indoor Digital Advertising Display 3840x2160 UHD 2000 nits 1850W
86 inch High Brightness Indoor Digital Advertising Display 3840x2160 UHD 2000 nits 1850W
Specifications
Brand Name :
Maxbright
Model Number :
M860EDCL
Certification :
CE
Place of Origin :
Shenzhen, China
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
50 sets / Month
Delivery Time :
4~5 weeks
Packaging Details :
Pearl cotton shock absorption + carton packaging + pallet
Panel Type :
a-Si Active Matrix TFT-LCD
Resolution :
3840 x 2160 RGB (4K) UHD
Brightness :
2000 nits
Power Consumption :
1850W
Operating Temperature :
-30C - 50C
Operating Voltage :
100 - 240 VAC 50-60Hz
Description

Maxbright 86" High Brightness Store Window Advertising Signage Display M860EDCL

LED Array Backlight Enhanced

Model: M860EDCL

FEATURES:

Active Matrix TFT-LCD Display

High Brightness 1500-2000 nits

3840 x 2160 Max. QWUXGA Resolution

Aspect Ratio: 16:9 in portrait mode

Wide Viewing Angles 178 deg (L/R/U/D)

Waterproof IP65 and Fashion Design

Media player box or mini PC Built-in (option)

Main Specs of 86” High Bright 4K Monitor

PANEL TYPE a-Si active matrix TFT-LCD IPS
ACTIVE AREA 1895.04 x 1065.96 mm
NATIVE RESOLUTION 3840 x 2160 RGB UHD
PIXEL PITCH 0.4935(H) x 0.4935(V) mm
COLOR 16.7M/1.07B 71% [CIE1931]
INTERFACE VGA, HDMI, DP option
. VIEWING ANGLE 89/89/89/89
BRIGHTNESS 1500-2000 cd/m2, LED Backlight enhanced
CONTRAST RATIO 1200:1, Dynamic contrast ratio: 8000:1
DIMMING Auto-dimming by Light Sensor
DIMMING RANGE 2000 nits to 300 nits 100% to 15%
RESPONSE TIME 8msec typical
REMOTE CONTROL Support for Full OSD Features
MEDIA PLAYER Media Player (RK3399) or i3/i5 CPU mini-PC
(option)
OPERATING VOLTAGE AC 100 ~ 240V 60/50Hz
POWER CONSUMPTION 1400W at 1500 nits, 1850W at 2000 nits
STANDBY MODE 5 Watt or less
ACCESSORIES AC Power Cord, Remote Controller
HDMI, VGA cable x 1
OPERATING Mini PC: Intel Core i5-6200U 2.5GHz, 2GB DDR
(option) 500GB HDD, 5 x USB ports, 1 x RJ45, WiFi

DIMENSION

2195(H) x 1365(W) x 230(D) mm, monitor part only

Basement or wall mount bracket option
WEIGHT 250 Kg approx. without air-con
Waterproof IP54 Enclosure w/ AR Vandal glass
COOLING Cooling fans controlled by MCU for semi-outdoor
2 x 600W industrial air-con for outdoor
ENVIRONMENTAL

Operating Temperature -20-45oC,

Wide temp. -30-50oC (option)
Operating Humidity 10%-85%
Storage Temperature -30-60oC
Storage Humidity 5%-90%
WARRANTY One Year

86 inch High Brightness Indoor Digital Advertising Display 3840x2160 UHD 2000 nits 1850W
