Transparent lcd display 21.5inch advertising display box with Multi angle display
The inside exhibit can be seen while the pictures or videos are displayed on LCD screen. To attract customer's attention on product brand with the combination of dynamic information and the actual product display.
This Transparent Video Showcase can be used in many applications: Jewelry, Gem Stone, Watch, Wine bottle, Cosmetics, Perfume set, Digital Camera, IPad/Mac book, Hand bag, High heel, and Museum Craft, etc .
Standalone version :
* Chipset: Mstar, support 1920*1080P video
* Main function: auto playback video in loop
* Support play list setup (times to play very file, timing of playing files)
* Functions: video+music+slide show+ebook+calendar+clock+timer on/off
* Support video formats: MPEG2, MPEG4, H.264, RMVB, AVI, DIVX,
(avi,mov,ts,mpg,ms2ts,mkv) etc, 1080p.max.
* Support audio formats: MP3, WMA, AC3 etc.
* I/O terminals: USB, SD card slot, HDMI input
* Audio output: built in loudspeakers 2pcs*5W
* Customized: boot logo/opening logo
* Multi-language: Chinese, English and so on
* Power Supply: AC input 100V-240V, DC output 12V 3A
* Accesorry: remote control, CE approved AC power adapter
Network windows version :
* Chipset:Intel I3 or I5 , support 1920*1080P video,
* DDR: 4GB
* HDD: 500GB
* I/O terminals:USB*4,VGA*1,HDMI*1,RJ45*1,Audio*1,MIC*1,DC IN*1
* Two-channel stereo audio output
* WiFi :802.11 B.G.N
or Android version
I/O :TF*1,USB*2,HDMI output*1,Earphone*1,RJ45*1,DCIN*1
WIFI Signage Display : 802.11b/g/n (WEP/WPA/WPA2)
Configuration description:
1. OS: Android 4.4 .2
2. CPU: Allwinner A83T , Octa core
3. DDR3 :1GB or 2GB
4. Internal storage: 8GB NAND FLASH
5. External memory: High-speed 8GB TF card(Max support 32GB)
Product Description for 21.5" LCD transparent advertising display box
Specification | |
Model No. | US-AD2105T |
Panel size | 21.5" |
Display area(mm)/mode | 476.64(W)×268.11(H) 16:9 |
Maximum resolution | 1920x1080 |
Display color | 16.7M |
Visual angle | 178°/178° |
Response time | 8ms |
Life(hrs) | >60,000(hrs) |
Input and output | |
USB | 1 ( USB2.0 interface) |
SD | 1 (Compatible MMC/MS) |
CF | 1(optional) |
Speaker | 2×5W |
OSD display( screen menu display) | |
Menu language | Chinese/English( Multiple Language Supported) |
Power | |
Power supply | 100~240V |
Input Voltage | DC 12V-2A |
Temperature | |
Working temperature | 0°C~50°C |
Storage temperature | -20°C~60°C |
Working humidity | 20%~85% |
Storage humidity | 10%~90% |
Appearance | |
Color/appearance | White/black |
Case | Acrylic+Aluminum |
Installation | Desk-top |
Specs | 640mm×420mm×250mm |
Quality Standard | ISO9001,CCC |
Detailed functions | |
Video format | AVI/MPEG1/MPEG2/MPEG4 |
Audio format | MP3 |
Image format | JPG |
Image resolution | 480P/720P/1080P |
Payment terms & Delivery | |
Sample Leading time | 10 ~ 12 working days(Black) |
20~25 working days(White) | |
Bulk Order Leading time | 10 ~ 12 working days(Black) |
15~17 working days(White) | |
Payment term | T/T-100% payment before production for sample, 30% deposit before production and 70% balance before shipping for bulk order |
Warranty | 1year |
Q: Are your company is factory?
A: Yes, we are factory direct sales, can help you save a lot of middle of the cost, give you the biggest discount.
Q: Product highlights attributes
A: Massive advertising program, time setting, remote control, human-kiosk interaction...
Q: How the digital signage plays the ad program
A: We have two ways, one by USB (manual replacement program), the second is through wifi, 3G, 4G, and cable remote replacement and playback programs
Q: Can help us make great advertising programs
A: Yes, we have software to help you create great advertising programs, simple operation, and has technical support and instructions.
Q: Optional version
A: a. Standalone version (via manual update via USB)
b. Internet version (Andrews and windows system option, both can use USB update program, and also wifi, 3G, 4G, and network cable remote replacement and playback programs
c. Touch version (added touch function base on the Internet version, human-kiosk interaction)
Q.What the difference between wall mounted style digital signage and free standing style digital signage
A: The only difference is the installation method, the wall mounted style digital signage is hanging on the wall, the free standing style digital signage is standing on the ground, other functions are the same
