Double Jacket SFTP LAN CABLE Fluke Test PE LSZH Cat 6 SFTP Cable
Double Jacket SFTP LAN CABLE Fluke Test PE LSZH Cat 6 SFTP Cable
Specifications
Brand Name :
JIANGHONG or OEM
Model Number :
SFTP CAT6(Copper)
Certification :
ISO,TLC
Place of Origin :
Sichuan, China
MOQ :
30500 Meters
Price :
Can Be Negotiated
Payment Terms :
L/C, T/T
Supply Ability :
3050000M per month
Delivery Time :
5-8Days
Packaging Details :
Carton+Pallet
Product name :
SFTP CAT6 (copper)
Conductor :
Bare copper
Sheath color :
Black
Conductor Structure :
Solid or stranded
Length :
305m/carton
Insulation material :
HDPE
Sheath Material :
LSZH PE PVC
Package :
Carton+pallet
Description

SFTP Copper Double jacket LAN CABLE Fluke Test 305m LSZH PE Network Cable

Description

SFTP CAT6 LAN CABLE adopts the standard twisted structure design, the transmission signal crosstalk is small, and it can upload and download and transmit at high speed. Double-layer shielding protection is adopted to make the entire channel more anti-interference and ensure the correct transmission of data information under high-intensity environmental electromagnetic interference. It is suitable for environments with special high performance requirements such as military, hospital, banking and financial systems.

Features


Bandwidth is standard 250 MHz.
Support 10-Gigabit Ethernet netword transmission requirements.

The double jacket can better prolong the service life of the product.


Performance

Electrical Characteristics
Frequency (MHz) ATT(≤dB/100m) NEXT(≥dB) ELFEXT(≥dB)
1 2.04 62.3 60.0
4 4.1 55.3 49.0
10 6.5 47.3 41.0
20 9.3 42.8 35.0
31.25 11.7 39.9 31.1
62.5 17.0 35.2 25.0
100 22.0 32.3 21.0

Company profile

SICHUAN JIANGHONG CABLE MANUFACTURE CO.,LTD,was founded in 1992,located in Jiangyou,Sichuan P.R.China.

BY 26 years development,company has become a modernized enterprise focus on development,manufacture of different cables for radio and TV network,Video monitoring network,FTTH communication and smart home network.Based on advanced production equipment,the annual capacity has reached up to 5 minllion km/year.

1. Experience:with more than 20 years production experience on cable industry . certified supplier for broadcasting and communication company in China domestic and overseas market .
2. Production line:supply different cables for radio and TV network , Video monitoring network , FTTH communication ad smart home network .
3. Certificate:Factory got ISO9001:2015 quality management certificate. ISO14001:2015 environmental management certificate and OHSAS18001:2007 occupational health and safety management system certificate

4. High-quality material:With strict supplier control and raw-material inspection .make sure the product quality stable and reasonable cost .offer high-quality fiber from well-know fiber company . offer self-inspection and 3rd-party test report.
5. Service:One stop service at customer’s convenience,offer solution based on customer's request .
6. Price:Reasonable cost based on quality guaranteed product .
