Specifications
Brand Name :
TW
Model Number :
Indoor FTTH
Certification :
SGS ROHS REACH ISO
Place of Origin :
DONG GUAN CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000KM/mouth
Delivery Time :
5working days
Packaging Details :
Wooden Drum
Brand Name of Fiber :
Corning ,Yofc,Draka, Fujikura...as Requirement
Color of Loose Tube :
Blue, Orange, Green, Brown
Strength Member :
Steel or FRP
Jacket Color :
Black, White
Installation Style :
Indoor & Outdoor Self-Support Drop Cable
Cable Dimension :
3.1*2.0mm
Cable Weight :
8.2kg/Km
Description

1 2 4 Core GJYXFCH FTTH Soft 245um Indoor Fiber Optic Cable


This FTTH 1-4 Core Indoor Fiber Optic Cable has been designed for access building cable with good performance and easy installation.


Structure &Properties


1. Good mechanical and environmental characteristics
2. FTTH 2 Core Indoor Fiber Optic Cable 's Flame retardant characteristics meet the requirements of relevant standard
3. The mechanical characteristics meet the requirements of relevant standard
4. Soft, flexible, easy to lay and splice and with big capacity data transmission
5. Meets various requirements of market and clients


Application

1.Outdoor wiring system

2.FTTH, terminal system

3.Indoor shaft, building wiring

Technical Date


ITEMS		 UNITS SPECIFICATION
Attenuation dB/km ≤0.4 at 1310nm ≤0.3 at 1550nm
Chromatic Dispersion ps/nm.km ≤3.5 at 1285nm ~ 1330nm ≤18.0 at 1550nm
Zero Dispersion Wavelength nm 1300 ~ 1324
Zero Dispersion Slope ps/nm2.km ≤0.095
Cut-off Wavelength (λcc, 22m of a cabled fiber) nm ≤1260
Mode Field Diameter um 9.2±0.5
Mode Field Concentricity um ≤0.8
Cladding Diameter um 125±1.0
Cladding Non-circularity % ≤1.0
Coating cladding concentricity error um ≤12.5
Coating Diameter um 245±10
Bending loss (Bare fiber) Radius :7.5mm x 1 turn dB ≤0.5 at 1550nm
Proof Test kpsi ≥100

Note : This datasheet can only be a reference, but not a supplement to the contract. Please contact our sales people

for more detailed information.
