10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
Specifications
Brand Name :
OEM
Model Number :
Fiber Optic SM SC-SC-9-1M
Certification :
CE,ROHS,REACH
Place of Origin :
CHINA
MOQ :
100pcs
Price :
usd1.4/pc
Supply Ability :
5000PCS PER DAY
Packaging Details :
1PC/PE BAG
Payment Terms :
Western Union, L/C, T/T
Delivery Time :
15 Working Days
Product name :
FTTH Drop Cable Patch Cord
Core :
2 Core
Fiber Type :
SM 9/125 G652D
Fiber type :
SM
Polish :
UPC,APC
Connector :
SC to SC
Cord type :
Simplex
Cable jacket :
LSZH
Color :
Yellow
Wavelength :
1310/1550nm
Insertion loss :
≤0.25dB(1310nm&1550nm)
Cable diameter :
2.0mm
Cable length :
1M
Operating temperature :
-40 to 85℃
Description

10 LC/UPC single-mode patch cords, 3.0mm simplex for FTTH, in a bag

10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper

Description

An Optical Fiber Pigtail is a fiber optic cable that has a connector added to one end to enable connection to a beam path. The Pigtail is a length of fiber that is permanently attached to a connector on one end only. Pigtails are assembled with a variety of connector types, including FC, SC, ST, LC, MU, and MTRJ, among others. There are three types of polished fiber end-faces available: PC, UPC, and APC. We employ advanced techniques and equipment to ensure the high quality of mass production.

10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper

Features

Low Insertion Loss

High Return Loss

Good Repeatability

Good Exchangeability

High Temperature Stability

Applications

Optical Fiber Communication Systems

Optic-fiber Data Communications

Optic-fiber Data Communications

Optic-fiber Access Networks

LAN Optic-fiber Sensors

Parameters

Mode Single mode Multi-mode
Polish UPC APC PC
Insertion Loss ≤0.2dB ≤0.3dB ≤0.2dB
Return Loss ≥55dB ≥65dB ≥35dB
Interchangeability ≤0.2dB
Salt Spray ≤0.1dB
Repeatability ≤0.1dB (1000 times)
Vibration ≤0.2dB (550Hz 1.5mm)
Temperature ≤0.2dB (-40+85 sustain 100 hours)
Humidity ≤0.2dB (+25+65 93 R.H.100 hours)
Apex Offset 0μm ~ 50μm
Radius of Curvature 7mm ~ 25mm
Standards-Compliant ROHS,IEC and GR-326

Fiber type Single mode:9/125-G652D
9/125-G657
Multi-mode: 50/125-OM2
62.5/125-OM1
50/125-OM3
Fiber Corning,China Fiber,other
Connector SC,FC,LC,ST,MU,DIN,MTRJ,E2000,MPO,SMA,D4 and others
Polishing PC,UPC,APC,MTRJ Male connector,MTRJ female connector
Cord type Simplex ,Duplex
Cable diameter 0.9mm ,2.0mm,1.8mm 3.0mm
Cable jacket PVC,LSZH,OFNR,OFNP
length(M) 0.5m,1m,3M,5m,10m,20m,200m or other
How to Choose The Right Fiber Optic Cable Type
The difference of OM4 and OM3 fiber mode as the following.
OM4 was developed specifically for VSCEL laser transmission and allows 10 Gig / second link distances of up to 550 Meters (compared to 300M with OM3).
The effective modal bandwidth for OM4 is more than double that of OM3.
For OM4 patch cable it is 4700 MHz.km while for OM3 it is 2000 MHz.km.
Designation
Fiber Dia.(μm)
Type
Fast Ethernet 100BASE-FX
1 Gigabit Ethernet 1000BASE-SX
1 Gigabit Ethernet 1000BASE-LX
10Gbps Ethernet 10GBASE
40Gbps Ethernet 40GBASE SR4
100Gbps Ethernet 100GBASE SR4
OM1
62.5/125
Multimode
2000M
275M
550M
33M
Not supported
Not supported
OM2
50/125
Multimode
2000M
550M
550M
82M
Not supported
Not supported
OM3(Laser Optimized)
50/125
Multimode
2000M
550M
550M
300M
100M(SR4)
100M(SR4)
OM4(Laser Optimized)
50/125
Multimode
2000M
550M
550M
400M
150M(SR4)
150M(SR4)
Singlemode
9/125
Singlemode
2000M
5km at 1310nm
5km at 1310nm
10km at 1310nm
N/A
N/A

10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper

10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper

10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
10PCS/bag sC /UPC-sC/UPC Simplex single-mode fiber optic patch cord Simplex 3.0mm FTTH fiber optic jumper
