1 Core FTTH Drop Cable with PVC / LSZH Jacket, Self-Supporting Fiber Optic Cable
This FTTH 2 Core Indoor Fiber Optic Cable has been designed for access building cable with good performance and easy installation.
Structure &Properties
1. Good mechanical and environmental characteristics
2. FTTH 2 Core Indoor Fiber Optic Cable 's Flame retardant characteristics meet the requirements of relevant standard
3. The mechanical characteristics meet the requirements of relevant standard
4. Soft, flexible, easy to lay and splice and with big capacity data transmission
5. Meets various requirements of market and clients
Technical Date
ITEMS | UNITS | SPECIFICATION |
Attenuation | dB/km | ≤0.4 at 1310nm ≤0.3 at 1550nm |
Chromatic Dispersion | ps/nm.km | ≤3.5 at 1285nm ~ 1330nm ≤18.0 at 1550nm |
Zero Dispersion Wavelength | nm | 1300 ~ 1324 |
Zero Dispersion Slope | ps/nm2.km | ≤0.095 |
Cut-off Wavelength (λcc, 22m of a cabled fiber) | nm | ≤1260 |
Mode Field Diameter | um | 9.2±0.5 |
Mode Field Concentricity | um | ≤0.8 |
Cladding Diameter | um | 125±1.0 |
Cladding Non-circularity | % | ≤1.0 |
Coating cladding concentricity error | um | ≤12.5 |
Coating Diameter | um | 245±10 |
Bending loss (Bare fiber) Radius :7.5mm x 1 turn | dB | ≤0.5 at 1550nm |
Proof Test | kpsi | ≥100 |
Packing & Shipping
Company Profile
Dongguan TW-SCIE Co., Ltd. is a subsidiary of Tewang Group. It was established in 2002. Since its establishment, the company has been adhering to the concept of "continuous innovation and pursuit of excellence", and has been committed to the research and development of optical fiber communication products and market expansion for a long time. Through unremitting efforts, it has developed into a comprehensive high-tech enterprise integrating R&D, production, sales and network engineering of optical fiber communication products. We rely on advanced equipment, mature technology and strict management to provide users with high-quality products and perfect pre-sales, sales and after-sales services. Relying on the tenet of "survive by quality, develop by innovation" and good reputation, the company has established strategic partnerships with many operators at home and abroad. The company currently has three series of products: optical cables, optical passive components, and optical fiber transceivers, which can provide customers with one-stop services.
Our Certificate:
REACH
ROHS
TLC Telecom Certificate
Environmental Management System Certification
ISO9001:2000
Utility Model Patent Certificate
Our Quality & Service
DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:
1. Consistently meeting for product quality and performance;
2. Timely delivery of products and services to meet our customer's requirements;
3. Ensuring that our people are properly trained so that they are better able to serve our customers.
WE LOOK FORWARD TO HEARING FROM YOU !
