Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable
Specifications
Brand Name :
TW-SCIE
Model Number :
FTTH
Certification :
ISO, RoHS, REACH, TLC
Place of Origin :
CHINA
MOQ :
Negotiable
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500KM per day
Delivery Time :
7-10 days
Packaging Details :
wooden drum
Fiber core :
1-24 core
Cable diameter :
Min 2.0mm±0.2mm
Outer sheath :
LSZH or PE
Strength member :
Aramid yarn
Cable color :
Yellow, Orange,Aqua
Description

Cable Factory Flat FTTH 1core G657A LSZH Indoor Butterfly Drop Cable


GJXFH FTTH Indoor Drop Cable uses butterfly flat structure, whose optical fiber unit is positioned in the centre. Two parallel Fiber Reinforce Plastic (FRP) strength members are placed at the two sides. Then, the cable is completed with LSZH sheath.

Features

1.Good waterproof performance
2.Low smoke, zero halogen and flame retardant sheath
3.Smaller diameter, simple structure, light weight, and high practicability
4.FRP strength member ensures anti- electromagnetic and crush resistance
5.Special low-bend-sensitivity fiber provides high bandwidth data transmission
6.Novel flute design, easily strip and splice, simplify installation and maintenance

7.Access network
8.Local area network (LAN)
9.Used end users directly cabling

10.Fiber optic communication system
11.FTTH indoor cabling and distribution

Application


1. Adopted to indoor distribution.
2. As pigtail of communication equipment
3. Suitable for communication equipment
4. Can be installed conveniently


Characteristics


1. Weight, low cost, and practicability.
2. Suitable for limited space field of the branch, indoor series
3. Laid to facilitate construction operations;part and the cable
4. Jacket use low smoke, halogen-free flame-retardant materials.
5. Prevent lightning and strong electric environment;
6. FRP or KFRP strengthen the component materials.

Requirement for Order


1. Fiber sort: Single mode G652,G655,G657, Multi mode 50/125,62.5/125,OM3,OM4.
2. Fiber brand: YOFC, Corning, Fiberhome Fujikura, OFS etc.
3. Sheath material: PE,LSZH, PVC( can be required).
4. Sheath color: Black ,can be required.
5. The fiber and tube color: according to stranded color, can be required.
6. The cable Size: shall be in accordance with the table, can be required.
7. Length of cable: generally is 2KM, can be required.
8. Other requirement:can be negotiated.

Specifications

Cable Type

FTTH Drop Cable

Fiber Count

1 Fiber

Construction

Butterfly Flat

Singlemode G.657A

Singlemode G.657A

Outer Jacket Material

LSZH (Black/White)

Strength Member Material

FRP

Cable Diameter

(2.0±0.1)×(3.0±0.1)mm

Weight

10kg/km

Tensile Strength (long/short term)

100/200N

Crush Load (long/short term)

300/1000 (N/100mm)

Bending Radius (long/short term)

10D/20D (mm)

Operating/Storage Temperature

-40 to +85 °C


Cable construction details :

Items

Description

Number of fiber

1core

Fiber

type

G657A

diameter

250µm

Strength member

material

Galvanized steel wire/FRP/KFRP

Cable sheath thickness

/

Max. 0.8mm/Min. 0.4mm

/

/

Outer sheath

material

LSZH

diameter

1.8±0.2mm

Cable size (Height * width)

3.0(±0.1) mm ×2.0 (±0.2)mm

Cable weight

8.5 KG±1KG

Installation Temperature range(ºC)

-20+60

Operation and transport temperature(ºC)

-40+70

Min Bending Radius(mm)

Long term

10D

Min Bending
Radius(mm)

Short term

20D

Min allowable
Tensile Strength(N)

Long term

40

Min allowable
Tensile Strength(N)

Short term

80

Crush Load (N/100mm)

Long term

500

Crush Load (N/100mm)

short term

1000


Fiber characteristic:

Fiber style

Unit

SM
G652

SM
G652D

MM
50/125

MM
62.5/125

MM
OM3-300

condition

nm

1310/1550

1310/1550

850/1300

850/1300

850/1300

attenuation

dB/km

≤

≤

≤

≤3.0/1.0

≤3.0/1.0

0.36/0.23

0.34/0.22

3.0/1.0

----

----

Dispresion

1550nm

Ps/(nm*km)

----

≤18

----

----

Dispresion

1625nm

Ps/(nm*km)

----

≤22

----

----

Bandwith

850nm

MHZ.KM

----

----

>=400

>=160

Bandwith

1300nm

MHZ.KM

----

----

>=800

>=500

Zero dispersion wavelength

nm

1300-1324

>=1302,
≤1322

----

----

>= 1295,
≤1320

Zero dispresion slope

nm

≤0.092

≤0.091

----

----

----

PMD Maximum Individual Fibr

≤0.2

≤0.2

----

----

≤0.11

PMD Design Link Value

Ps(nm2*k
m)

≤0.12

≤0.08

----

----

----

Fibre cutoff wavelength λc

nm

>= 1180,
≤1330

>=1180,
≤1330

----

----

----

Cable sutoff
wavelength λcc

nm

≤1260

≤1260

----

----

----

MFD

1310nm

um

9.2+/-0.4

9.2+/-0.4

----

----

----

1550nm

um

10.4+/-0.8

10.4+/-0.8

----

----

----

Numerical
Aperture(NA)

----

----

0.200+/
-0.015

0.275+/-0.
015

0.200+/-0
.015

Step(mean of bidirectional
measurement)

dB

≤0.05

≤0.05

≤0.10

≤0.10

≤0.10

Irregularities over fiber
length and point

dB

≤0.05

≤0.05

≤0.10

≤0.10

≤0.10

Dicontinuity

Difference backscatter
coefficient

dB/km

≤0.05

≤0.03

≤0.08

≤0.10

≤0.08

Attenuation uniformity

dB/km

≤0.01

≤0.01

Core dimater

um

50+/-1.0

62.5+/-2.5

50+/-1.0

Cladding diameter

um

125.0+/-0.1

125.0+/-0.1

125.0+/-0.1

125.0+/-0.1

125.0+/-0.1

Cladding non-circularity

%

≤1.0

≤1.0

≤1.0

≤1.0

≤1.0

Coating diameter

um

242+/-7

242+/-7

242+/-7

242+/-7

242+/-7

Coating/chaffinch
concentrically error

um

≤12.0

≤12.0

≤12.0

≤12.0

≤12.0

Coating non circularity

%

≤6.0

≤6.0

≤6.0

≤6.0

≤6.0

Core/cladding conentricity error

um

≤0.6

≤0.6

≤1.5

≤1.5

≤1.5

Curl(radius)

um

≤4

≤4

----

----

----


Packing & Shipping

Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop CableFlat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable

Company Profile


DONGGUAN TW-SCIE Co., Ltd. is a high-tech enterprise group in China devoted to communications undertakings with our own impoters and exporters rights. Since its founding, high quality products an strong co-operations have enabled the enterprise to stably and rapidly grow into a specialized communication

Manufacturer supplier and engineering service provider the most complete product line-up and specifications in the fiber and cable industry of China.

The enterprise is possessed of a passel of faithful, intelligent, conscientious talents. While bending ourselves to following with the worldwide advanced development and application, we build up cooperation ties with many scientific research academy.

Detailed Images

Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable

Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop CableFlat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable

Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable

Flat FTTH 1 Core Indoor Digital Fiber Optic Cable G657A LSZH Butterfly Drop Cable

Our Quality & Service

DONGGUAN TW-SCIE CO., LTD. is committed to providing the highest quality optical fiber cable products & services to our customers by:

1. Consistently meeting for product quality and performance;

2. Timely delivery of products and services to meet our customer's requirements;

3. Ensuring that our people are properly trained so that they are better able to serve our customers.

Solving your problem is our priority, pls feel free to contact us !
