160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
Specifications
Brand Name :
DALITE
Model Number :
LLDL-803
Certification :
CE
Place of Origin :
CHANGZHOU CITY CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
40000sets/month
Delivery Time :
2-6 weeks
Packaging Details :
Form + Carton
Rated Power :
30-240W
Efficiency @3030 :
>150LM/W
Efficiency @5050 :
>160LM/W
CCT :
3000-6500K
IP rating :
IP67
Impact Resistance :
IK09
Description

LED modules, LED street lighting, Die-Cast Aluinium ,PC lens, LLDL-803,Outdoor LED Street Lights

Code : LLDL-803

The Most Comprehensive & High Efficiency Led Light Solution
Key advantages

  • LED modules with flexible combinations of LEDs
  • Separate LED modules for better heat dissipation
  • Vavious luminous efficiecy on options 160 lm/w Max
  • PC lens Protector,for IP67 Max
  • Two fixing system:Post top or Side-entry mounting
Characteristics
Code LLDL-803-30W LLDL-803-60W LLDL-803-90W LLDL-803-120W LLDL-803-150W LLDL-803-180W LLDL-803-210W LLDL-803-240W LLDL-803-270W
Size(D*W*Hmm) 502*346*120 582*346*120 662*346*120 742*346*120 822*346*120 902*346*120 982*346*120 1062*346*120 1142*346*120
Rated Power 30W 60W 90W 120W 150W 180W 210W 240W 270W
Efficiency @3030 150LM/W
Efficiency @5050 160LM/W
Luminous Flux@3030 3500LM 9000LM 13500LM 18000LM 22500LM 27000LM 31500LM 36000LM 40500LM
Luminous Flux@5050 4800LM 9600LM 14400LM 19200LM 24000LM 28800LM 33600LM 38400LM 43200LM
Beam Angle T2/T3/T4/T5
CCT 3000-6500K
CRI Ra>70
Input Voltages 120-277V
Frequency 50-60Hz
Power Factor >0.95
Protection Index IP67
Impact Resistance IK08
Dimensions
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
Photometric Distributions
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
Application example
160LM/W 240W IP67 IK09 T5 LED Street Light Waterproof
