Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Specifications
Brand Name :
DALITE
Model Number :
LTYL-909F
Certification :
CE,UL
Place of Origin :
CHANGZHOU CITY CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
40000sets/month
Delivery Time :
2-6 weeks
Packaging Details :
Contoured foam + Carton
Material :
Die-cast aluminum
Color :
Grey/Dark grey/Black or as requirement
CRI :
Ra>70
IP rating :
IP65
Impact Resistance :
IK08
Working Temperature :
-40-50℃
Working Humidity :
10%-95%
Description

140LM/W Luminious Efficiency Excellent Thermal Management IP65 Waterproof Long Lifetime Outdoor Led Landscape Lights
Model: LTYL-909F

European and American design style.Adopt aerodynamic design, take heat away quickly, keep low temperature for heat sink and LED chip for long lifespan and high light efficiency.

Key advantages

• Patent number:ZL 2018 3 0024938.3
• Clean, smooth design blending harmoniously into outdoor environments.
• Heavy-duty die-cast aluminum housing.
• UV stabilized polyester powder coating finish for durability and
corrosion resistance.
• Precision engineered individual lenses made of optical grade polycarbonate
for maximum light intensity, with tempered glass cover to protert the optics.
• Excellent thermal management
• IP65 protection degree
• Luminious efficiency up to 140LM/W.

Characteristics
Code LTYL-909F
Size(D*W*Hmm) 600*600*564
Rated Power 30W/60W/100W/150W
Beam Angle(Fixed lens) 90°*90°/T2-S/T3-M/T4
Efficiency @2835 140LM/W
Luminous Flux 4200/8400/14000/21000LM
CCT 3000-6500K
CRI Ra>70
Input Voltages 120-277V
Frequency 50-60Hz
Power Factor >0.95
Protection Index IP65
Impact Resistance IK08
Working Temperature -40-50℃
Working Humidity 10%-95%
Electrical Class Class I
Finishing Standard color(RAL 7035,7042,9006,9007) other colors upon request
Service Life >50000H



Dimensions
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Photometric Distributions
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Details Picture
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Installation Diagram
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
Application example
Waterproof IP65 LED Outdoor Landscape Lighting 140LM/W Thermal Management
