Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Specifications
Brand Name :
DALITE
Model Number :
LTYL-909L
Certification :
UL, DLC, CE, CB, ENEC
Place of Origin :
CHANGZHOU CITY CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
40000sets/month
Delivery Time :
2-6 weeks
Packaging Details :
Form + Carton
Material :
Die-cast aluminum
CRI :
Ra>70
IP rating :
IP65
Impact Resistance :
IK08
Working Temperature :
-40-50℃
Working Humidity :
10%-95%
Description

High Efficiency lighting, PC diffuser cover, Die-cast Aluminum, Patent design, LTYL-909L Outdoor Urban LED Lighting

LTYL-909L

The nature of light LTYL-909 series
Light plays an integral role in defining the spaces in which we live.
As part of the pedestrian experience we want to be reminded of spaces we value. The most valued “people spaces” in the urban environment are those that tie to nature.
Dalite’s Nature family of LED luminaires uses seamless organic design elements with an unregimented symmetry as seen and reflected in nature.
Various LED optical technology allows the Nature to deliver precise and elegant illumination that enhances the world around us.
From site to street
Complementary design across products connects multiple spaces.
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Key advantages
  • Clean, smooth design blending harmoniously into outdoor environments.
  • Heavy-duty die-cast aluminum housing.
  • UV stabilized polyester powder coating finish for durability and corrosion resistance.
  • Precision engineered individual lenses made of optical grade polycarbonate for maximum light intensity, with PC diffuser cover to protert the optics.
  • Patent design
  • Excellent thermal management
  • IP65 protection degree
  • Full series certification: UL, DLC, CE, CB, ENEC
  • Luminous efficiency up to 140LM/W
  • High Quality injection die-casting Alu large decorative pole base,suitable for Max 12M pole.
Characteristics
Code LTYL-909L
Size(D*W*Hmm) 600*600*564
Rated Power 30/60/100/150W
Beam Angle T2/T3/T4/T5
Efficiency @3030 140LM/W
Luminous Flux 4200/8400/14000/21000
CCT 3000-6500K
CRI Ra>70
Input Voltages 120-277V
Frequency 50-60Hz
Power Factor >0.95
Protection Index IP65
Impact Resistance IK08
Working Temperature -40-50℃
Working Humidity 10%-95%
Electrical Class Class I
Finishing Standard color(RAL 7035,7042,9006,9007) other colors upon request
Service Life >50000H
Dimensions
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Photometric Distributions
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
Application example
Die Cast Aluminum 150W T5 Urban Wall Lights PC Diffuser Cover 140LM/W 21000LM
