Summarize:
Our temporary warehouse tent has been widely used in the world since 2007. All event tent is made of aluminium alloy frame and PVC fabric tarpaulin.
Description:
Usually the frame is made of hard pressed 6061/T6 aluminum alloy which was qualified by National Center of Analysis and Testing for Nonferrous Metals and Electronic Materials. After wind test and destructive test by professional organizations, the aluminum structure was proved t be strictly conducted in EU quality control standards. Roof covers and sidewalls are made of flame retardant double PVC coated polyester textile strictly based on the European standard DIN 4102B1, M2 while is has features of waterproof and UV protected.
We can offer cutomized size of the industrial tents which range from 3m width to 60m width. Usually eaves height (high side) is 2.5m to 3m for normal circumstance. Of course it can be 4m/5m/6m in height if you need. This aluminium structure design using modular units, length 3m or 5m spacing can be increased or decreased. Normally the roof covers are made of 850g/sqm PVC fabric and the sidewalls are made of 850g/sqm PVC fabric.
Except for normal storage tent, this series tents also widely used in outdoor wedding, festival party, celebration activity, sports and exhibition events. Some special circumstance, it also can be used for temporary storage and temporary workshop and emergency relief purposes.
Features:
1, Special modular design with less components , safe and secure , easy to assemble and dismantle , easily transport.
2, Hard pressed GB6061/T6 aluminum alloy is in high strength and has been anodized for corrosion resistance.
3, The PVC tarpaulins is durable, waterproof, easy cleaning, UV protected and flame restardant.
4, The aluminium structure of industrial tent can resist up to 100km/h wind and 0.5kn/sqm snow.
5, Internal space without any load-bearing pillars ensure 100% internal space usage.
6, Widly usage which can used for exhibitions, outdoor events, temporary activity, temporary warehouse, emergency relief and so on.
Specifications:
Model | Span width | Eave height | Riddge height | Bay Distance | Length | Frame Profile |
WT3A | 3m | 2.5m | 3.0m | 3m | 6m+3m more | 84x48x3mm |
WT4A | 4m | 2.5m | 3.2m | 3m | 6m+3m more | 84x48x3mm |
WT5A | 5m | 2.5m | 3.4m | 3m | 6m+3m more | 84x48x3mm |
WT6A | 6m | 2.5m | 3.6m | 3m | 6m+3m more | 84x48x3mm |
WT8A | 8m | 2.5m | 3.9m | 3m | 9m+3m more | 84x48x3mm |
WT9A | 9m | 2.5m | 4.1m | 3m | 9m+3m more | 84x48x3mm |
WT10A | 10m | 2.5m | 4.3m | 3m | 9m+3m more | 84x48x3mm |
WT6B | 6m | 3m | 4.2m | 3m | 6m+3m more | 120x48x3mm |
WT9B | 9m | 3m | 4.5m | 3m | 9m+3m more | 120x48x3mm |
WT12B | 12m | 3m | 5.1m | 3m | 9m+3m more | 120x48x3mm |
WT10C | 10m | 3m | 4.7m | 5m | 10m+5m more | 120x68x3mm |
WT12C | 12m | 3m | 5.1m | 5m | 10m+5m more | 120x68x3mm |
WT15C | 15m | 3m | 5.4m | 5m | 10m+5m more | 120x68x3mm |
WT10D | 10m | 4m~6m | 5.8m~7.8m | 5m | 10m+5m more | 166x88x3mm |
WT12D | 12m | 4m~6m | 6.0m~8.0m | 5m | 10m+5m more | 166x88x3mm |
WT15D | 15m | 4m~6m | 6.5m~8.5m | 5m | 10m+5m more | 166x88x3mm |
WT18D | 18m | 4m~6m | 7.0m~9.0m | 5m | 10m+5m more | 166x88x3mm |
WT10E | 10m | 4m~6m | 5.8m~7.8m | 5m | 10m+5m more | 203x112x4mm |
WT12E | 12m | 4m~6m | 6.0m~8m | 5m | 10m+5m more | 203x112x4mm |
WT15E | 15m | 4m~6m | 6.5m~8.5m | 5m | 10m+5m more | 203x112x4mm |
WT18E | 18m | 4m~6m | 7.0m~9.0m | 5m | 20m+5m more | 203x112x4mm |
WT20E | 20m | 4m~6m | 7.2m~9.2m | 5m | 20m+5m more | 203x112x4mm |
WT21F | 21m | 4m~6m | 7.4m~9.4m | 5m | 20m+5m more | 255x112x4.5mm |
WT25F | 25m | 4m~6m | 8.0m~10.0m | 5m | 20m+5m more | 255x112x4.5mm |
WT30F | 30m | 4m~6m | 8.8m~10.8m | 5m | 30m+5m more | 255x112x4.5mm |
WT40G | 40m | 4m~6m | 10.5m~12.5m | 5m | 40m+5m more | 300x125x5mm |
WT50G | 50m | 4m~6m | 12.1m~14.1m | 5m | 50m+5m more | 300x125x5mm |
WT60G | 60m | 4m~6m | 13.7m~15.7m | 5m | 60m+5m more | 300x125x5mm |
Optional Accessories:
WT's industry temporary warehouse tents have a variety of configurations which is available for purchase, its function and purpose has been further expanded, common configuration are following: side wall covering with transparent PVC window, ground anchors, columns bearing plate, interior ceiling, glass walls glass door, ABS hardware wall, transparent tarpaulin and side wall coverings, floor systems, drainage channels, other special tents units.
We can also offer many optional relevant accessories as following:
1, Transparent PVC Windows for good lighting
2, Glass Wall and Glass Door System
3, Optional Solid Wall System : ABS, color steel, rocky, etc.
4, Rolling door or Flexible lifting door System
5, Ceiling or Flooring System
6, Fixed system : Expansion screw, Loading plate, Ground anchor, etc.
7, Rain Gutters
8, Backup PVC tarpaulin
