Summarize:
WT'soutdoor exhibition tent has been widely used in the world since 2007. All event tent is made of aluminium alloy frame and PVC fabric tarpaulin. We usually use the hard pressed 6061/T6 aluminium alloy to build the frame which had passed the wind test and destructive test by professional organizations. The aluminum structure of large outdoor tent was proved to be strictly conducted in EU quality control standards. Roof covers and sidewalls are made of flame retardant double PVC coated polyester textile strictly based on the European standard DIN 4102B1, M2 while is has features of waterproof and UV protected.
Description:
Cutomized size of the exhibition marquee tents range from 3m width to 60m width and the eave height is usually 2.5m to 6m for normal circumstance. This aluminium structure design using modular units, length 3m or 5m spacing can be increased or decreased. Normally the roof covers are made of 850g/sqm PVC fabric and the sidewalls are made of 850g/sqm PVC fabric.
This series tents has been widely used for outdoor events, weddings, festival parties, celebration activities, sports events and so on. Some special circumstance, it also can be used for temporary storage and temporary workshop and emergency relief purposes.
Features:
1, Special modular design with less components , safe and secure , easy to assemble and dismantle , easily transport.
2, Hard pressed GB6061/T6 aluminium alloy is in high strength and has been anodized for corrosion resistance.
3, The PVC tarpaulins is durable, waterproof, easy cleaning, UV protected and flame restardant.
4, The aluminium structure can resist up to 100km/h wind and 0.5kn/sqm snow.
5, Internal space without any load-bearing pillars ensure 100% internal space usage.
6, Widly usage for exhibitions, outdoor events, temporary activity, temporary warehouse, emergency relief and so on.
Specifications:
Model | Span width | Eave height | Riddge height | Bay Distance | Length | Frame Profile |
WT3A | 3m | 2.5m | 3.0m | 3m | 6m+3m more | 84x48x3mm |
WT4A | 4m | 2.5m | 3.2m | 3m | 6m+3m more | 84x48x3mm |
WT5A | 5m | 2.5m | 3.4m | 3m | 6m+3m more | 84x48x3mm |
WT6A | 6m | 2.5m | 3.6m | 3m | 6m+3m more | 84x48x3mm |
WT8A | 8m | 2.5m | 3.9m | 3m | 9m+3m more | 84x48x3mm |
WT9A | 9m | 2.5m | 4.1m | 3m | 9m+3m more | 84x48x3mm |
WT10A | 10m | 2.5m | 4.3m | 3m | 9m+3m more | 84x48x3mm |
WT6B | 6m | 3m | 4.2m | 3m | 6m+3m more | 120x48x3mm |
WT9B | 9m | 3m | 4.5m | 3m | 9m+3m more | 120x48x3mm |
WT12B | 12m | 3m | 5.1m | 3m | 9m+3m more | 120x48x3mm |
WT10C | 10m | 3m | 4.7m | 5m | 10m+5m more | 120x68x3mm |
WT12C | 12m | 3m | 5.1m | 5m | 10m+5m more | 120x68x3mm |
WT15C | 15m | 3m | 5.4m | 5m | 10m+5m more | 120x68x3mm |
WT10D | 10m | 4m~6m | 5.8m~7.8m | 5m | 10m+5m more | 166x88x3mm |
WT12D | 12m | 4m~6m | 6.0m~8.0m | 5m | 10m+5m more | 166x88x3mm |
WT15D | 15m | 4m~6m | 6.5m~8.5m | 5m | 10m+5m more | 166x88x3mm |
WT18D | 18m | 4m~6m | 7.0m~9.0m | 5m | 10m+5m more | 166x88x3mm |
WT10E | 10m | 4m~6m | 5.8m~7.8m | 5m | 10m+5m more | 203x112x4mm |
WT12E | 12m | 4m~6m | 6.0m~8m | 5m | 10m+5m more | 203x112x4mm |
WT15E | 15m | 4m~6m | 6.5m~8.5m | 5m | 10m+5m more | 203x112x4mm |
WT18E | 18m | 4m~6m | 7.0m~9.0m | 5m | 20m+5m more | 203x112x4mm |
WT20E | 20m | 4m~6m | 7.2m~9.2m | 5m | 20m+5m more | 203x112x4mm |
WT21F | 21m | 4m~6m | 7.4m~9.4m | 5m | 20m+5m more | 255x112x4.5mm |
WT25F | 25m | 4m~6m | 8.0m~10.0m | 5m | 20m+5m more | 255x112x4.5mm |
WT30F | 30m | 4m~6m | 8.8m~10.8m | 5m | 30m+5m more | 255x112x4.5mm |
WT40G | 40m | 4m~6m | 10.5m~12.5m | 5m | 40m+5m more | 300x125x5mm |
WT50G | 50m | 4m~6m | 12.1m~14.1m | 5m | 50m+5m more | 300x125x5mm |
WT60G | 60m | 4m~6m | 13.7m~15.7m | 5m | 60m+5m more | 300x125x5mm |
Optional Accessories:
WT's exhibition event tent has a variety of configurations available for purchase, its function and purpose has been further expanded, common configurations are following: side wall covering with transparent PVC window, ground anchors, columns bearing plate, interior ceiling, glass walls glass door, ABS hardware wall, transparent tarpaulin and side wall coverings, floor systems, drainage channels, other special tents units.
We can also offer many optional relevant decoration accessories as following:
1, Transparent PVC Windows
2, Glass Wall and Glass Door System
3, ABS Solid Wall System
4, Ceilings and Inside Curtain
5, Wooden Flooring System
6, Ground Anchors
7, Rain Gutters
