3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
3.0mm Mini Indoor Fiber Optic Cable Types GJFV GJFH For MPO Use
Specifications
Place of Origin :
CHINA
Brand Name :
SKYLYNN or OEM, ODM
Certification :
ISO, ROHS, CE
MOQ :
2KM
Packaging Details :
WOODEN DRUM, CARTON
Delivery Time :
5-10 DAYS
Payment Terms :
T/T, L/C, WEST UNION
Supply Ability :
100,000 cores
Model NO. :
GJFJV
Delivery :
EXW/FOB/CIF
Country of Origin :
GUA,CN
Description

3.0mm Multi-core Indoor Micro Cable GJFV GJFH for MPO Use

​Description

Indoor Mini cable are used for LAN connections, patch cords, MTP/MPO, pigtails and internal point-to-point links(data cabinets, equipment rooms, wall outlets and computers).
with 250um fibre, the cable is suitable for industry standard connectors and can be easily made into assemblies for MTP/MPO patch cords.
they can also be supplied in PVC (OFNR & OFNP) or LSZH jackets,

Features

  • Good uniformity of the outer diameter of tight buffer fiber and excellent strippability.
  • Good performance of flame-retardant
  • Steady performance both in extremely high and low temperature.
  • Excellent geometrical dimension of the fiber .

Optical Characteristics

　 G.652D 50/125μm 62.5/125μm
Attenuation (+20℃) @850nm 　 ≤3.0 dB/km ≤3.0 dB/km
@1300nm 　 ≤1.0 dB/km ≤1.0 dB/km
@1310nm ≤0.36 dB/km 　 　
@1550nm ≤0.22 dB/km 　 　
Bandwidth (Class A) @850nm 　 ≥500 MHz·km ≥200 MHz·km
@1300nm 　 ≥1000 MHz·km ≥600 MHz·km
Numerical Aperture 　 0.200±0.015NA 0.275±0.015NA
Cable Cut-off Wavelength λcc ≤1260nm 　 　

Cable Specification

Items Specifications
Fiber Count 4f-24f
　 Dimension 250±15μm
Color Coated Fiber Color Blue,Orange,Green,Brown,Gray,White,Red,Black,Yellow,Purple,Pink,Aqua
Outer Jacket Dimension 3.0±0.2mm
Material PVC, LSZH, OFNP, OFNR
Color SM: Yellow, MM: Orange, OM3: Aqua, OM4: Purple, OM5: Green
Cable Weight 9 kg/km
