No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
Specifications
Place of Origin :
CHINA
Brand Name :
SKYLYNN or OEM, ODM
Certification :
ISO, ROHS, CE
MOQ :
2KM
Packaging Details :
WOODEN DRUM
Delivery Time :
5-10 DAYS
Payment Terms :
T/T, L/C, WEST UNION
Supply Ability :
100,000 cores
Model NO. :
GYFXTY
Delivery :
EXW/FOB/CIF etc.
Country of Origin :
GUA,CN
Description

Outdoor Central Loose Tube No-metal Duct Cable GYFXTY

Description

The fibers, 250μm, are positioned in a loose tube made of a high modulus plastic. The tubes are filled with a water-resistant filling compound. Over the tube. water-blocking material is applied to keep the cable watertight. Two parallel Fiber Reinforced Plastics (FRP) are placed at the two side. The cable is completed with a polyethylene(PE) sheath.

Application

-Adopted to indoor and outdoor distribution.
-Suitable for communication equipment serve.

Characteristics

-Good mechanical and temperature performance.
· High strength loose tube that is hydrolysis resistant.
· Special tube filling compound ensure a critical protection of fiber.
· FRP ensure tensile strength.
· Small diameter, light weight and friendly installation.

Technical Data

Fiber count Cable outer dia(mm) Cable weight(kg/km) Min.bending radius(mm) Permissible tensile force(N) Permissible pressure force(N/100mm)
Static Dynamic Short-term Long-term Short-term Long-term
2--12 8 70 10D 20D 1500 600 1000 600
14--24 8.7 81 10D 20D 1500 600 1000 600

No Metal FRP Optical Fiber Duct Cable 24F 2f Fiber Optic Cable GYFXTY 6mm
