Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access
Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access
Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access
Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access
Specifications
Brand Name :
ESTEL
Model Number :
162061018050001
Certification :
ISO9001, CE, 3C, FCC, TLC, IP55
Place of Origin :
Shenzhen, China (Mainland)
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability :
8,000 sets per month
Delivery Time :
15-20 working days
Packaging Details :
Wooden case with pallets
Material :
Galvanized steel, double wall with insulation
Temperature Control :
Air conditioner
Alarm sensors :
Water Sensor, Smoke Sensor, Temperature and Humidity Sensor ,Shock Sensor ,Door Sensor
Door type :
With one front door and one back door
Certificates :
CE
Protection level :
IP65
Description

Air Conditioner Cooling Outdoor Cabinet Four Wheels With Front / Rear Access

1. Cabinet Overview

This series telecom cabinets can be configured to meet specific requirements with a range of options also available including cable management, thermal management, environmental protection and integration. provides superior protection for telecom and communication equipment from the ravages of changing weather, temperature, moisture and other hazards.

2. Cabinet Features

1 External dimensions WxDxH 600x1000x1800mm.
2 Device installation There is 42U 19” rack inside of the cabinet.
3 Material Galvanized steel
4 Doors One front door, one back door,hidden zinc alloy hinge.
5 Door lock Outdoor special steel lock, lock cylinder assembled with protective cover, lock body assembled with three-point lock device.
6 Door stopper Door stopper is installed on the inside of the cabinet door
7 Door structure Grooved door with seal rubber strip, attached to the inner side of the door, waterproof and dustproof.
8 Air inlet and outlet The air inlet and air outlet are all installed with a filter, and the filter can be cleaned and replaced.
9 Rack type Include standard 19“ rack inside the cabinet, high universality. Special rack or electrical lining board inside the cabinet can be custom made.
10 Cable inlets

Cable inlets at the bottom of cabinet
11 Lamp LED Lighting
12 Color Outdoor polyester light grey RAL7035 coating or custom made.
13 Protection Rating

IP65,This cabinets protects againstrain ,dust,

splashing water and damage from external
14 Surface Finish Power Coated
15 Mounting type wall mount, floor mount, pole mount

16

 Cooling system Air conditioner cooled

3. Cooling System

There are 4 fans installed on the front door.

Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access

4. Ground Bars Installation

Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access

5. Package

5.1 Using wooden case with pallet

5.2 There are 4 wheels at the bottem of the cabinet,easy to move.

Four Wheels Outdoor Communication Cabinets Galvanized Steel With Front / Rear Access
