IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure
Specifications
Brand Name :
ESTEL
Model Number :
ECA005EA
Certification :
ISO9001, CE, 3C, FCC, TLC, IP55
Place of Origin :
Shenzhen, China (Mainland)
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, L/C,D/A, Western Union, Paypal, etc
Supply Ability :
8,000 sets per month
Delivery Time :
15-20 working days
Packaging Details :
Wooden case with pallets
Mounting method :
Embeded
Input voltage :
AC 110V±15% 50/60Hz
Cooling capacity L35/L35 :
500 W
Ingress Protection :
IP55
Certificates :
CE
Refrigerant :
R134A
Description

IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure

1. Key Features

  • Remote measuring, remote communication, remote control, which can realize multiple automatic protec-tion and comprehensive self-testing function;

  • Strict process control and famous brand components to ensure high quality and reliability of this prod-uct;

  • Fit for harsh condition (T3), R134a refrigerant ;

  • Multiple self-protection design , RS485 communication port (MODBUS-RTU protocol);

  • Built-in condensate water evaporating device is optional;

  • LED display, all the settings can changed at the field;

  • The heating function is optional;

  • Dry contact alarm output, NO/NC optional;

2. Application

The product is widely used in outdoor communication cabinets, electrical cabinets, industrial cabinets and other occasions need heat dissipation. Create a cool, dry and safe environment for the operation of equipment and electrical enclosure

3. Parameters

Type Parameters
Dimensions (Include flange) 582*352*175mm
Dimensions(Without flange) 546*315*175mm
Weight 15 kg
Mounting method Embedded
Application temperature -40℃ -70 ℃
Working temperature -15℃ -55 ℃
Input voltage AC 110V±15% 50/60Hz
Cooling capacity L35/L35 500 W
Power consumption L35/L35 270 W
Airflow 150 m3/h
IP grade IP 55
Refrigerant R134A
Noise 60 dB(A)
Surface treatment RAL7035

IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure

4. Installation instructions

IP55 Electrical Enclosure Air Conditioner 110VAC 500W For Outdoor Telecom Enclosure

In order to avoid short circuit of air duct, it is suggested to make effective isolation between inner air inlet and outlet.

This product is free of cover, customers don’t need to install additional cover.

1. If the customer needs to in-stall a protective cover, in order to ensure enough circulation of air, the opening rate of the air inlet and outlet should be greater than 60%. It is very important to prolong the unit life and reduce the maintenance frequency.

2. The air inlet and outlet of the protective cover should pre-vent short circuit of air duct, so that the air-con can get the best cooling effect.
