33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
Specifications
Brand Name :
ESTEL
Model Number :
ET70100180-EQ
Certification :
ISO9001
Place of Origin :
China
MOQ :
1PC
Payment Terms :
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
1800PCS per month
Delivery Time :
15 to 20 days
Packaging Details :
Wooden Case with Pallet
External Size :
700mm×1000mm×1800mm(W×D×H)
Color :
Grey RAL7035
Material :
Galvanized steel, single wall with heat insulation
User space :
Standard 33U 19" rack
Surface :
Outdoor powder coating
Cooling :
AC220V 50Hz 1500W air conditioner and fan
IP Level :
IP55
Base Height :
200mm
Description

33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control

Waterproof 33U 19 Inch Insulated Temperature Antirust Control Outdoor Equipment Cabinet

Summary

The outdoor telecom cabinet ET70100180-EQ has been designed to house sensitive electronic equipments for use in communications (such as satellite modem, modem redundancy controller, Ethernet switch, Ethernet router, etc.), transportation and rail infrastructure projects including SISS, CIS, CCTV, communications, networking etc.

33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control

Features

  • Outdoor anti corrosion powder coating
  • The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment
  • Standard 19“ rack for installation
  • IP grade: IP55
  • Cabinet cooling: air conditioner and fans
  • The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding
  • High integration, compact structure, easy installation and migration on later stage
  • Anti-theft three point lock, excellent keyhole protection device

Technical Parameters

Configuration Item Technical Parameter
Cabinet Body Model ET70100180-EQ
Size

External Size: 700mm×1000mm×1800mm(W×D×H)

Internal Space: 19” 33U

Base height: 200mm
Component The whole cabinet is composed of three parts: top cover, cabinet body and base. The installation method is floor mounted.
Material Galvanized steel, single wall with heat insulation
Structure

(1) One front door

(2) Anti-theft three point lock(support padlock)

(3) Door stopper is installed for keep door when door is open

(4) Door with good sealing, waterproof and dustproof

(5) Include standard 33U 19“ rack inside the cabinet, high compatibility.

(6) Equipped with cable manager

(7) Cable inlets at the bottom of cabinet
Surface Treatment Outdoor anti-corrosion powder coating
Color Grey RAL7035
Ingress Protection IP55
Working Temperature -40°C～+75°C
Cooling Method Air Conditioner

Cooling Capacity: 1500W

Power Supply: 220VAC, 50Hz

On front door
Fan Two AC220V fans + one temperature controller
Illumination LED Lamp AC220V LED lamp with one lamp switch

Cabinet Drawing

33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control

Similar Cabinet Pictures

33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control

Our factory View

33U 19 Inch Outdoor Rack Mount Enclosure Insulated Temperature Antirust Control
