1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel
Specifications
Brand Name :
Estel
Model Number :
ET8085210
Certification :
ISO9001, CE, RoHs
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
5000 pcs/month
Delivery Time :
3-4 weeks
Packaging Details :
Wooden Case
Material: :
Galvanized Steel
Surface Finish: :
Outdoor Powder Polyester Coating
Protection Level: :
IP55
Dimension :
850×800×2025mm
Type: :
Outdoor Cabinet
Equipment Installation Method :
19" rack
Description

1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel

1. Application

It is designed for storing electrical components. It is also ideal for industrial application to store large number of components. Electrical enclosure is also applicable on street lighting, solar power and traffic control. Electrical enclosure is a multi-functional enclosure. It is ideal application for outdoor, indoor and small building.Our electrical enclosure is also suitable for installations where space is limited.

2. Features

>>> The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

>>> All the cables, sealing and heat insulation used in the cabinet are made from flame retardant materials, which comply with GB5169.7 test A

>>> IP55 protection level.

>>> Output voltage, current limits and alarm levels are easily adjustable.

3. Technical Parameters

Item Type Technical Parameter
Structure Dimension External Dimension: W×D×H 850×800×2025mm
Layout 1 compartment
Equipment Installation Method 19” rack
Door With one front door, and anti-theft three point lock for outdoor cabinet (support padlock).
Material (1) Cabinet left side, right side and back: sandwich structure panel, outer plate: 0.5mm galvanized steel, inner plate: 0.5mm galvanized steel, insulation: 45mm flame retarded EPS. (2) Cabinet door and base: outer plate: 1.5mm galvanized steel, inner plate: 0.8mm galvanized steel, insulation: 40mm PEF. (3) Cabinet roof: sandwich structure panel (outer plate: 0.5mm galvanized steel, inner plate: 0.5mm galvanized steel, insulation: 45mm flame retarded EPS.) + 1.0mm galvanized steel.
Ingress Protection IP55
Temperature Control Cooling air conditioner and fans
Lighting LED lamp 48V LED lamps (immovable), with protective circuit breaker
Temperature Temperature Working Temperature: -40°C ~ +55°C
Storage Temperature: -50°C ~ + 70°C
Transport Temperature: -50°C ~ +70°C
Humidity Relative Humidity 5% ~ 100%
Pressure Air Pressure 62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)
Radiation Intensity Solar Radiation Intensity 1120 ×(1±5%)W/m2

4. Accessories List

No. Item Quantity Unit Specs
1 Outdoor Telecom Cabinet 1 PC

(1) External Dimension: W×D×H 850×800×2025mm

(2) One compartment: 19” 40U

(3) With one front door, and anti-theft three point lock for outdoor cabinet (support padlock).
2 Air Conditioner 1 PC

Cooling capacity: 1.5KW,

Power Supply: AC110V, 60Hz.
3 Auxiliary Direct Ventilation Fans 2 PC DC48V
4 LED Lamp 1 PC DC48V
5 LED Lamp Switch 1 PC One for controlling LED lamp on/off
6 Power Distribution Unit 1 PC

Grade B Lightning Proof AC Input: 63A/2P×1; AC Output: 16A/1P×4;

DC Output: 16A/1P×4

Input Voltage: AC220V, 50Hz
7 Package 1 PC Wooden Case

5. Cabinet Picture:

1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel

6. Connection and Fastening

· Use anti-loose threaded connection as structure and bearer connection. Anchor bolt for fixing cabinet use hot dip galvanized bolts.

· Door hinges use inner hinge mode.

1 Compartment IP55 Outdoor Telecom Cabinet 0.5mm Galvanized Steel

FAQ

Q1: Are you a manufacturer?
A: Yes, we are a experienced manufacturer with our own design and production lines.
Q2. Do you have any MOQ limit for outdoor cabinet ?
A: Low MOQ, 1pc for sample checking is available.
Q3: Can I get sample order?
A: Yes, we would like to get your sample order for testing our quality, the sample cost is paid by the customer.
Q4: Are you able to customize items with design or logo?
A: Yes, OEM & ODM is available.
