400mm Height Outdoor Wall Enclosure
400mm Height Outdoor Wall Enclosure
400mm Height Outdoor Wall Enclosure
400mm Height Outdoor Wall Enclosure
400mm Height Outdoor Wall Enclosure
400mm Height Outdoor Wall Enclosure
Specifications
Brand Name :
ESTEL
Model Number :
ET301540
Certification :
ISO9001, CE,
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
3000 pcs/month
Delivery Time :
3-4 weeks
Packaging Details :
woonde case
External Dimension :
W×D×H 300×150×400mm
Material :
Galvanized steel
Color :
RAL7035, powder coating finish
Protection level :
IP55
Layout :
One compartment, include one back plate
Installation Mode :
Wall mount
Description

Anti-Corrosion Steel IP55 Outdoor Wall Enclosure Compact Telecom Box For Battery Power Supply

1. Application

The ET301540 outdoor cabinet is mainly used in wireless communication base station, such as 4G/5G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.

2. Features

(1) The cabinet is dustproof, sunproof and rainproof, which is used in outdoor environment.

(2) Cabinet cooling: direct ventilation.

(3) The layout of the cabinet is reasonable, which will facilitate cable access, fixing and grounding. There are cable inlet individually for power cable, signal cable and optical cable.

(4) All the cables used in the cabinet are made from flame retardant materials.

3. Technical Parameters

Item

Type

Technical Parameter

Structure

Dimension

External Dimension: W×D×H 300×150×400mm

Layout

1 compartment

Equipment Installation Method

Including one back plate

Door

With one front door and cabinet lock

Material

Galvanized steel, single wall without insulation

Ingress Protection

IP55

Temperature Control

Cooling

Direct ventilation

Temperature

Temperature

Working Temperature: -40°C ~ +55°C

Storage Temperature: -50°C ~ + 70°C

Transport Temperature: -50°C ~ +70°C

Humidity

Relative Humidity

5% ~ 100%

Pressure

Air Pressure

62kpa ~ 101kpa (similar to 0m ~ 5000m altitude)

Radiation Intensity

Solar Radiation Intensity

1120 ×(1±5%)W/m2

4. Accessories List

No.

Item

Quantity

Unit

Specs

1

Outdoor Cabinet

1

PC

(1) External Dimension:

W×D×H 300×150×400mm

(2) One compartment, include one back plate. Used for install one board, one power supply and one 7AH battery

(3) With one front door and cabinet lock

(4) Material: galvanized steel, single wall without insulation

(5) Including cable entry gland on the bottom

(6) IP grade : IP55

(7) Installation method: wall mount

2

Package

1

PC

Carton with wooden pallet

4. Cabinet Dimension

External Dimension: W×D×H 300×150×400mm

400mm Height Outdoor Wall Enclosure

6. Cabinet Diagram

400mm Height Outdoor Wall Enclosure400mm Height Outdoor Wall Enclosure

400mm Height Outdoor Wall Enclosure

7. Cabinet Pictures

400mm Height Outdoor Wall Enclosure

400mm Height Outdoor Wall Enclosure400mm Height Outdoor Wall Enclosure
