1200W 220V Telecommunication Enclosure Outdoor 19 Inch Rack Cabinet

1. Outdoor Equipment Enclosure

Outdoor Telecom Equipment Cabinet is mainly used in wireless communication base station, such as communication/network integrated service, 4G system, access/transmission switching station, emergency communication/transmission, etc. The cabinet is equipment cabinet, including 19” equipment installation rack, with air conditioner and fans on cabinet door.

2. Selling points and Feature Of Outdoor Equipment Enclosure

• High reliability
• maintenance-free
• fast assembly
• suitable for harsh environment
• High integration
• small footprint
• short construction period
• reduce the construction cost

3. Specification Of Equipment Enclosure

Cabinet And Accessories List

4. Technical Parameters

Item Technical Parameter

Working temperature range: -40℃~ +60℃

Sorage temperature range: -50℃~ +70℃

Transport temperature range: -50℃~ +70℃

Relative Humidity 5%-- 100%

Air Pressure 62kpa~ 101kpa (similar to altitude 0m ~ 5000m)

Radiation Intensity 1400* (1±5%) W/m2

5. Application Of Equipment Enclosure

Wireless communication base station such as 4G system, communication/network integrated service, access/transmission switching station, emergency communication/transmission, etc.

6. Equipment Enclosure Structure

(1) MATERIAL:STEEL

(2) STRUCTURE: DOUBLE WALL

(3) INSULATION: WITH HIGH-DENSITY FOAMING BOARDS BETWEEN THE TWO WALLS

(4) SIZE: ACCORDING TO YOUR DRAWING

7. Door and Door Lock

(1) Cabinet door options: vertical hinge door, horizontal hinge door.

(2) The door limit device can limit the door position when it is open.

(3) The door limit function is automatically activated when the door is open, and should be

canceled manually when the door is closed.

8. Dimension

According to your requirements.

9. Cable Inlet

All feeder cable and other external cables all use bottom wiring method.

There are eight cable inlets at the bottom of the cabinet.

10. Door lock theft proof design

Damage resistance of the theft proof lock meets GA/T 73-1994 "Mechanical Anti-theft Lock"class B requirement,supporting padlock.

Three theft lock
