Specifications
Brand Name :
T&C
Model Number :
P0082
Certification :
ISO9001
Place of Origin :
China
MOQ :
39 square meters
Price :
$29-61/square meter
Payment Terms :
L/C, , Western Union, MoneyGram, T/T
Supply Ability :
153000square meters/month
Delivery Time :
within 16 days
Packaging Details :
Hardware packed in solid carton box; 3. Roof and sidewall in professional PVC carry bag
Connectors :
Hot-DIP Galvanized
Function :
sport event
Side Wall :
PVC walls,glass wall,ABS wall
Wind loading :
100km/h
Tent application :
3-60M
Fixing Solution :
ground anchor
Description

Big Sport tent,Clear span event tent,Curve tent arch tent event from Asian games tent supplier

Frame struss: hard pressed extruded aluminium 6061/T6(15HW) which can last more than 20 years.

Fabric cover: high quality double PVC-coated polyester textile, 100% waterproof, flame retardant to DIN4102 B1, M2, CFM, UV resistant, tear resistant, self-cleaning ability, etc.

Connector: strong hot-dip galvanized steel

Allowed temperature condition: -30 degree Celsius~+70 degree Celsius

Wind load: max. 100km/h (can be reinforced)

Snow load: 75kg/sqm (snow can't stay if use big degree roof pitch design)

Easy to be assembled and dismantled, movable.

No pole inside, 100% available interior space.



Our Series:

Type Span Width Bay Distance Eave Height Ridge Height Main Profile
CBT 15m/49.2' 5m/16.4' 3.87m 8m 204x120x4mm(4-channel)
CBT 20m/65.6' 5m/16.4' 3.87m 8.8m 204x120x4mm(4-channel)
CBT 25m/82' 5m/16.4' 3.87m 9.9m 204x120x4mm(4-channel)
CTH 20m/65.6' 5m/16.4' 3.89m 8.9m 300x120x5mm(4-channel)
CTH 25m/82' 5m/16.4' 3.89m 10m 300x120x5mm(4-channel)
CTH 30m/98.4' 5m/16.4' 3.89m 11.2m 300x120x5mm(4-channel)
CTH 40m/131.2' 5m/16.4' 3.89m 13.5m 300x120x5mm(4-channel)
The length can be extended by 5m bay such as 15m,20m,30m,40m...Customized size is available.


Produce Show:

Asian Games Sporting Event Tents Flame Retardant With Strong Hot Dip Galvanized Steel

Our service:

1. We offer a one-year warranty for all our sold products. Within the warranty period, we shall offer free on-site repair. At the same time, we shall offer paid service in case of the following circumstances.
A. Damage born of artificial behavior or irresistible natural phenomenon;
B. Breakdown or damage due to improper operation;
C. Breakdown or damage due to transformation, decomposition and assembly of products.
2. Upon receipt of repair notice, we shall arrive at the site within seven working days and settle the problem.
3. A user may consult related technical questions via after-sales telephone and receive a definite solution. Business service tel.: +8618027240112/ 020-39048997


Packaging & Delivery

Packaging Details:
1) aluminum packed in Iron box or plastic pallet.
2) steel parts packed in Iron box or wooden case.
3) PVC Covering packed in professional PVC bag.

Delivery Detail:25-30 Working Days


FAQ:

Q: What size tent is necessary for your special event?

  • A person must first determine tent usage. If a tent is being used for dining purposes and round tables are being used allow 10-12 square feet per person. If banquet style tables are being used allow 8-10 square feet per person.If the purpose is for cocktail service allow five to six square feet per person. Contact us for all your specific questions and more information on tent types.

Q: Has your tent product been certified?

  • Yes.Our tent product has passed the engineering tests and gained the America And Australia structural engineering certificates. Besides, the PVC fabric used for roof covers and sidewalls has passed the fire tests and gained the flame retardant certificates issued by America, Australia, New Zealand, and Britain.

Q: Is your tent strong and stable enough? How about the wind loading?

  • Yes.The main frameworks (upright support and roof beam) are manufactured with high impact extruded anodized aluminum (6061/T6) so our tent structure is safe and strong and can resist wind up to 100 km/hr.

Q: How long is the warranty period?

  • Guarantee one year. During the warranty period, we shall repair or replace the damaged part accordingly because of any damage due to quality problem.
