Specifications
Brand Name :
TRIGONPOWER
Model Number :
SMR03-B-3
Certification :
VDE, CE, ROHS
Place of Origin :
CHINA,P.R.
MOQ :
5000
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
> 100K / month
Delivery Time :
35days after order confirmed
Packaging Details :
carton / pallet
TYPE :
shaded pole induction motor
STYLE :
Synchronous Reduction Motor
CODE :
SMR03-B-3
Insulation Class :
H CLASS
RATED FREQUENCY :
50 / 60HZ
WORKING TEMPERATURE :
T 120
Description

microwave oven fan motor AC 110~127V / AC 220V ~ 240V

Description:

FAN MOTOR. It is a kind of motor with steel fans. It could supply enough and stable wind power to make a stable heat convection system in oven. When this motor working, its rotating speed could reach more than 3000rpm and it could output energy more than 30W.

In our production, we use the exclusive materials and special treatment methods in the manufacture process of gears, magnetic cylinder, and coils. With these measures, we could guarantee that our motor could stably operate long time under the high temperature work environment.

Specification:

Type Shaded Pole Motor
Use Classification Fan Motor Cooler Fan
Using Occasion Electrical Oven Induction Cooker
Nominal Voltage AC 110~127V / AC 220V~240V
Nominal Frequency 50 / 60 HZ
Output Power 30~60W 40~80W
Output Rpm >2500 >2000
Output Torque NONE NONE
Working Temp. T 120 T 80
Product Code SMR03 SMR04
Terminal FASTON 0.8X6.3 / 2 PCS MINIFIT
Ground Connector YES
Insulation Class H CLASS

Easy to install, clean, and maintenance

All of motor products are all manufactured according to the standard appearance and install dimension. So you could easily install or remove the motors from the oven machine. The motor appearance is a sealed box, it could keep things like dust out. And the surface of the product is very smooth, it is convenient for clean and maintenance.

Working stably under high temperature

Many of our motor products would work under high temperature environments. So we choose the raw materials for motor which all have good high temperature resistance properties. At the same time, we also choose the good quality oil or grease with high temperature resistance to guarantee the Lubrication. So the motors could work stably under the high temperature, at least 125 degrees centigrade.

COMPONENTS RAW MATERIAL TEMP. RESISTANCE
Metallic parts (shell, gears, etc.) Galvanized steel / stainless steel >1500 ℃
Coil former nylon (PA66) >200 ℃
Wire for coil copper >1000 ℃
Oil or grease >125 ℃
