Wide Paddle Spring Rocker Switch KCD4 Double Pole 16A 125VAC Silver Plating
Wide Paddle Spring Rocker Switch KCD4 Double Pole 16A 125VAC Silver Plating
Specifications
Brand Name :
CHIMAI
Model Number :
KCD4
Certification :
CE,ROSH
Place of Origin :
CHINA
MOQ :
100PCS
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
100k/pcs/month
Delivery Time :
7 work days
Packaging Details :
plastic bag
Material :
NYLON 66
Lamp :
LAMP
Color :
RED
Terminal :
4 pins
Current :
10A
Description

Double Pole Wide Paddle Switches KCD4 Rocker Switch 16A 125VAC

Switch Product Description


The Main Technical Parameters
Item KCD4 Rocker Switch
Mterial PA66
Rating 16A 125VAC/10A 250VAC
Contact Resistance ≤50MΩ
Insulation Resistance ≥500VDC100mΩ
OperatingTemperature -25C~+85C
Ambient Temperature -10ºC~+85 ºC
Dielectric Strength 1500VAC,1 Minute
Type ROCKER SWITCH
Elactric life >=10000 Cycles
Electrical Life >=50000 Cycles
Terminals & Mid pins Copper
Contacts Copper with compound silver
Terminals & Mid pins Copper
--Production Material---
Base PLASTIC Nylon 66 T85
Button plastic PC
Copper parts such as terminal Copper
Terminal surface treatment Silver plating
Contact Ag or Composite silver
Spring Tungsten steel
Cover plastic PC

Wide Paddle Spring Rocker Switch KCD4 Double Pole 16A 125VAC Silver Plating
