Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Bespoke Electrical Steatite Ceramic Resistor Base / Resistance Ceramic Case llight base
Specifications
Brand Name :
FFTC
Certification :
ISO9001:2008
Place of Origin :
YIXING, CHINA
MOQ :
1000pcs
Price :
Negotiation
Payment Terms :
MoneyGram, T/T
Supply Ability :
1000000/year
Delivery Time :
3 - 4 weeks
Packaging Details :
carton and wooden crate
Feature :
High Temperature Resistance
Color :
White
Raw material :
Steatite ceramic
Application :
Industrial Ceramic
Shape :
Custom-shaped
Type :
Insulating Ceramics
Item :
High Frequency Steatite Ceramic Pipe/Sleeve For Transformer
Description

Bespoke electrical ceramic resistor base resistance ceramic case

Product Description

1. Name: steatite ceramics/Talcum porcelain
2. Size: as customers' drawing
3. Type: Insulating Ceramic
4. Producing Method: Hot pressing/Dry pressing
5. Design: According to client's drawing or samples
6. Feature:
(1) Many kinds of insulated ceramics available
(2) Good lead-heat capability
(3) It can satisfy constant's technical request
(4) High resistance
(5) High temperature and high voltage resistant

Steatite ceramic parts are usually small and are formed from dry powder in a compaction press.
The parts are then fired in the kiln. Diamond abrasives are used to grind parts to size for high tolerance applications

Item Test Condition Unit&Symbol Steatite Ceramic / C221
The main chemical ingredient Steatite
Bulk Density g/cm3 ≥2.6
Maximum Use Temperature ≥1000℃
Water absorption % 0
Rohs Hardness HRA ≥75
Compressive Strength 20° C MPa ≥800
Fracture Toughness Mpa ≥120
Dielectricity constant 1MHz.20℃ ετ 5.5
Dielectric strength KV/mm 18
Volume Resistivity 20℃ Ω.cm20℃ > 1012

Advantages

Steatite ceramic parts are usually small and are formed from dry powder in a compaction press.
The parts are then fired in the kiln. Diamond abrasives are used to grind parts to size for high tolerance applications.

1) A variety of specifications available.
2) Satisfy various technical request
3) Lower medium spoilage
4) Good insulation performance and high temperature resistance
5) Stiffness texture
6) Used in all electric products, electric heating products and wear resistant machinery parts.

About us

1. We are one of the leading manufacturer specialized in designing and manufacturing industrial ceramics with experience of more than 10 years in China

2. Manufacturing according to the ISO9001:2008 quality control system guidelines.

3. Our products are widely recognized and trusted by users and can meet continuously developing economic and social needs.

4. Workers are locals in china, low production cost.
