High Performance Oxygen Gas Analyzer 316 Grade Stainless Steel Material
High Performance Oxygen Gas Analyzer 316 Grade Stainless Steel Material
High Performance Oxygen Gas Analyzer 316 Grade Stainless Steel Material
High Performance Oxygen Gas Analyzer 316 Grade Stainless Steel Material
Specifications
Brand Name :
PhyMetrix
Model Number :
POA-200
Place of Origin :
China
MOQ :
1
Payment Terms :
T/T,
Delivery Time :
1-2weeks
Connectors :
Quick Disconnect Fittings
Material :
316 Grade Stainless Steel
Display :
O2 Curve
Weight :
2.85kgs
Measurement :
Oxygen Concentration
Processor :
32-Bit High Speed Processor
Function :
Bluetooth
Flow Rate :
1L/min
Description

IP68 Protection From Any Harsh Environment, Oxygen Gas Analyzer , Trace Oxygen Gas Analyzer

Performance

Operating Conditions

Measurement Ranges 0-10ppm,0-100ppm,0-1000ppm,0-1% Operating Humidity Less than 95%(Non-Condensing)
Resolution 0.01ppm Operating Temp 0℃ to +45 ℃
Response Time

<10s(100ppm-1%)

<25s(0-10ppm)

 Inlet Gas Pressure 0.5-30psig
Repeatability +/-0.5% FS Flow Rate <1 LPM
Electrial Specifications Mechanical Specifications
Display 3.5”LCD,320*240 Screen Resolution Protection Intnsically Safe,Class 1,Div 1 Group B,C,D
Battery Li-ion rechargeable,8 hours on full charge Dimensions

Height:7.08”

Width:5.60”

Depth:5.75”
Input Charge Voltage 115/230VAC Weight 2.85KG

High Performance Oxygen Gas Analyzer 316 Grade Stainless Steel Material
